4. If the camera is turned sideways to look vertically at a scene, you can remove the sun shroud then re-
install it to cover the camera's new angle of view.

Zooming and Focusing the Camera

In the camera web browser interface or the Avigilon Control Center software, use the camera's Image
l
and Display settings to zoom and focus the camera.
a. Use the zoom buttons to zoom the camera in or out.
b. Click Auto Focus to focus the lens.
c. Use the focus near and far buttons to manually adjust the focus.

(Optional) Configuring microSD Card Storage

To use the camera's SD card storage feature, you must insert a microSD card into the card slot.
It is recommended that the microSD card have a write speed of class 10 or better. If the microSD card does
not meet the recommended write speed, the recording performance may suffer and result in the loss of
frames or footage.
1. Insert a microSD card into the camera.
CAUTION — Do not force the microSD card into the camera or you may damage the card
and the camera.
2. Access the camera's web interface to enable the onboard storage feature. For more information, see
the Avigilon High Definition H4 and H5 IP Camera Web Interface User Guide.

Configuring the Camera

Once installed, use one of the following methods to configure the camera:
Zooming and Focusing the Camera
13
