4. Technical data

Speed n :
0
Cutting thickness
Running time max.:
Battery pack: Li-Ion / 7.2 V d. c. / 1.3 Ah
Charging time:
Protection class:
L sound pressure level:
pA
L sound power level:
WA
K uncertainty
Vibration a
hv
K uncertainty
Weight:
Battery charger
Mains voltage
Output
Rated voltage
Rated current:
Sound and vibration were measured in accordance
with EN ISO 3744.

5. Before starting

5.1 Charging the battery pack (Figure 3)
Connect the charger to the charging station
(Figure 3).
Check that your mains voltage is the same as
that marked on the rating plate of the battery
charger. Plug the battery charger in a socket-
outlet. The red LED (Figure 3 / Item 6) comes on
to indicate that charging voltage is available.
The battery pack is being charged. An empty
battery pack requires a maximum charging period
of 3 to 5 hours. The temperature of the battery
pack may rise slightly during the charging
operation. This is normal.
As soon as battery pack is fully charged, the red
LED (Fig. 3/Item 6) extinguishes
30.06.2011 10:49 Uhr Seite 9
If the rechargeable battery fails to charge, check
whether there is voltage at the socket outlet.
1600 rpm
Timely recharging of the battery pack will help it
8 mm
serve you well for a long time. Recharging is always
necessary when you notice a drop in the toolʼs
60 min
performance.
Never allow the battery pack to become fully
3-5 h
discharged. This will cause it to develop a defect.
III
80.6 dB
Do not use the equipment when it is connected to the
charger.
93 dB
3 dB(A)
Important!
≤ 2.5 m/s²
It is prohibited to remove or bridge any of the
switching elements installed on the tool by the
1.5 m/s²
manufacturer (e.g. by securing a button to the
1.1 kg
handle) as this would prevent the tool from
switching off automatically and result in high risk
of injury.
Under no circumstances are you to use the shrub
230 V ~ 50 Hz
cutter with the telescopic long handle fitted.

6. Operation

9 V DC
350 mA
The area to be cut must first be cleared of stones
and other solid objects. The safety lock-off (Fig.
1/Item 3) prevents the tool being started
unintentionally. Activate the safety lock-off (Figure 1 /
Item 3) by pushing it forward and pressing the
ON/OFF switch (Figure 1 Item 4) at the same time.
To switch off the tool, let go of the ON/OFF switch
(Figure 1 / Item 4).
The equipment can be used to cut small hedges and
shrubs.
Hold the equipment slightly tilted in the direction of
the hedge you want to cut.
Start by cutting the sides of the hedge working from
the bottom up, and finally cut the top of the hedge.
Make sure that there are no foreign bodies in or
alongside the hedge, which could damage the
blades.
When is the best time to trim hedges?
As a general rule, hedges which lose their leaves
in the autumn should be trimmed in June and
October.
Hedges which do not lose their leaves should be
cut in April and August.
