Concourse Smart Wheels User Instruction Manual page 4

2.4 You may now connect the charging unit to a Power Point and
begin charging for the first time . You will notice an LED light just
below the wheels charging point that should appear RED when
CHARGING
2.5 Remove the remote control unit from it's packaging and
connect the USB charging cable . Now connect the Remote USB
Charging Cable to a USB Charging Port .
1 2
IMPORTANT: PLEASE ENSURE BOTH THE WHEELS AND REMOTE ARE FULLY CHARGED AND KEPT ON CHARGE AT ALL
TIMES BETWEEN ROUNDS OF GOLF. ONLY REMOVE THE CHARGER FROM THE WHEELS WHEN YOU ARE READY TO
PLAY. ALSO, AVOID PARTIAL CHARGING WHICH MAY AFFECT LONG TERM BATTERY LIFE.
concoursegolf.com
charging begins, and then turn GREEN once the wheels are fully
charged .
FULL CHARGE
Whilst this can be done via a computer's USB, it is
recommended to use a USB charger that connects directly to
mains power for the most effective and quickest charge .
3
6
User Instruction Manual | Version 6.0
2.6 When charging begins, you will notice the middle light on the
remote illuminate to Red indicating charging is in process . Once
the remote is completely charged the light will turn green .
CHARGING
2.7 Once both your Smart Wheels and remote are fully charged
please follow the disconnection instructions below very carefully .
CHARGER DISCONNECTION
1 2
IMPORTANT : ONCE BOTH YOUR WHEELS ARE FULLY CHARGED AND A GREEN LED IS
SHOWING ON BOTH WHEELS, FIRST TURN OFF THE CHARGER AND THEN REMOVE THE
POWER LEAD FROM THE OUTLET BEFORE DISCONNECTING THE WHEELS.
concoursegolf.com
When you disconnect the remote, it will automatically switch off
along with the green light .
FULL CHARGE
(LIGHT TURNS GREEN)
3
7
User Instruction Manual | Version 6.0
