Concourse TRAVEL GUARD CBM3 Instruction Manual

Download this manual

CBM3

INSTRUCTION

MANUAL

TRAVEL GUARD

Need help?

Do you have a question about the TRAVEL GUARD CBM3 and is the answer not in the manual?

Page 1 CBM3 INSTRUCTION MANUAL TRAVEL GUARD...
Page 2 Travel guard. In the kit provided you will find the following components (fig 1) to be fitted to the section of the buggy (fig 2). Travel guard Screw driver Fig. 1 Travel guard kit parts Fig. 2 Travel guard fitted to buggy...
Page 3 Place your bag and buggy on a flat surface and open Handle parallel to ground, until the handle is sitting resting on leg. parallel to the ground (fig 3). Note: It is important that the buggy is open in this exact position in order to fit the new travel guard.
Page 4 Place section A into section B as indicated by arrows and apply pressure with your thumb (fig 5). Apply pressure Fit “A” and “B” together Fig. 5 begin to fit travel guard While continuing to apply downward pressure with your thumb, using the screwdriver provided, carefully guide section “A”...
Page 5 Once section “A” has been successfully inserted into section “B” you will be Top tab locked over buggy able to complete the fitting process by locking over the top tab of the travel guard (fig 7). Fig. 7 Fit top of travel guard to buggy You have now completed the process and the buggy should look like...
Page 6 To see the CBM3 in action visit concoursegolf.com...
