Concourse Smart Wheels User Instruction Manual page 3

1.0
EQUIPMENT CHECK
IMPORTANT: TO MAXIMISE YOUR BATTERY LIFE, PLEASE READ THE CHARGING INSTRUCTIONS (SECTION 2.0)
PRIOR TO CONNECTING TO A POWER POINT FOR THE FIRST TIME.
SMART WHEELS
OPTIONAL
SMART WHEELS
CARRY CASE
REMOTE CONTROL
POUCH
concoursegolf.com
AXLE CHARGER POWER CHARGER POWER
CABLE (PART 1)
CABLE (PART2)
SOFTWARE
UPGRADE CABLE
REMOTE
REMOTE
CONTROL REMOTE CONTROL
CHARGING CABLE
MOUNT
4
User Instruction Manual | Version 6.0
2.0
CHARGING INSTRUCTIONS FOR WHEELS & REMOTE
2.1 Remove Smart Wheels from packaging and place face down .
2.2 Remove the two charger power cables
) (2 parts) and connect
to each other as shown below .
1 2
5 6
ENSURE BOTH WHEELS
ARE CONNECTED
IMPORTANT: DO NOT CONNECT
CHARGER TO POWER POINT UNTIL
BOTH CHARGER POWER CABLES ARE
CONNECTED TO THE WHEELS .
concoursegolf.com
2.3 Now connect corresponding charging sockets to each wheel .
Ensure these cables are firmly connected to the wheels, and
charger power cables connected before connecting to the
power point in step 6 .
3 4
If you have purchased the
7
optional Travel Case and once
you are familiar with the charging
process you may connect
and charge the wheels whilst
remaining in the Travel Case.
5
User Instruction Manual | Version 6.0
