- Page 1 CBM3 BUGGY 4TH WHEEL FITTING INSTRUCTIONS Version 1.2 1300 650 059 | concoursegolf.com...
- Page 2 THANK YOU FOR YOUR PURCHASE OF THE CBM3 4TH WHEEL We recommend you familiarise yourself with these instructions and follow the steps outlined to ensure your 4th wheel is secured properly and functions the way it is intended.
- Page 3 1 X Allen Key FITTING THE MOUNTING BLOCK STEP 1 Before fitting the 4th wheel remove your CBM3 Buggy from your bag. Unfold the buggy and place on a stable work bench (or table) with the underside facing upwards as shown.
- Page 4 SECURING THE MOUNTING BLOCK STEP 2 Now take a Metal Securing Strap and place it around the top of the Mounting Block and main frame. You will see two points where screws secure the Metal Securing Strap with the Mounting Block. Take two of the small screws and the Allen Key and attach the strap to the Mounting Block.
- Page 5 SECURING TO THE MAIN FRAME STEP 3 LONGER Turn your CBM3 over so you can SCREW AT TOP see the ends of the Metal Securing Straps. Take the longer threaded screw to secure the top Metal Securing Strap. Using the flat washer, then spring washer in front of the hexagonal nut, secure the strap as indicated.
- Page 6 ATTACHING / REMOVING THE 4TH WHEEL Note: When preparing to play, we recommend that you attach the 4th wheel as the last step in setting up before use. When stowing the buggy after use, we recommend you OPEN remove the 4th wheel as the very first step before removing all other wheels and folding the buggy flat.
- Page 7 1300 650 059 | concoursegolf.com Version 1.2...
- Page 8 For customer support or product enquiries, please contact Concourse Golf. info@concoursegolf.com concoursegolf.com 1300 650 059...
