GridAdvisor Series II smart sensor

LED installation indication

The LEDs provided on the GridAdvisor Series II smart
sensor provide annunciation during the installation of device
to verify proper load current is present.
Table 2. GridAdvisor Series II Smart Sensor LEDs Provided
Sequence Step (in order)
Current present below 10 Amps
Current present below 50 Amps
Current present above 50 Amps
Programming sensor
Please refer to Programming Guide S1150-20-2 for
instructions on connecting to sensor with Bluetooth
module and/or programming device with ProView NXG
software.

Support

Eaton is proud to offer a comprehensive collection of
support resources for users requiring additional information
or assistance in the setup, operation, and troubleshooting
of GridAdvisor Series II smart sensor and other equipment
from Eaton.
For technical support, contact EAS Support at 800-815-2258
or EAS-Support@Eaton.com, or contact your local Eaton
representative.
6
Installation Instructions MN915001EN June 2016
Source LED
RED Moving Bar Sequence for Direction
AMBER Moving Bar Sequence for Direction
Green Moving Bar Sequence for Direction
®
Load LED
RED Moving Bar Sequence for Direction
AMBER Moving Bar Sequence for Direction
Green Moving Bar Sequence for Direction
