1.2.5 Disposal Instruction

1.3 Installation

1.3.1 Before Starting Repair Work

1. Disconnect FC101 from mains (and external DC
supply, if present.)
2. Wait as stated in the table below for discharge of
the DC-link:

1.3.2 Side-by-Side Installation

The frequency converter can be mounted side-by-side and requires the clearance above and below for cooling.
Frame IP class
H1
H2
H3
H4
H5
H6
H7
H8
H9
H10
NOTE
With IP21/Nema Type1 option kit mounted, a distance of 50 mm between the units is required.
4
Equipment containing electrical components
must not be disposed of together with domestic
waste.
It must be separately collected with electrical
and electronic waste according to local and
currently valid legislation.
3 x 200-240 V
IP20 0.25-1.5 kW/0.33-2 Hp
IP20 2.2 kW/3 Hp
IP20 3.7 kW/5 Hp
IP20 5.5-7.5 kW/7.5-10 Hp
IP20 11 kW/15 Hp
IP20 15-18.5 Kw/20-25 Hp
IP20 22-30 kW/30-40 Hp
IP20 37-45 kW/50-60 Hp
IP20
IP20
MG18A302 - VLT
VLT HVAC Basic Drive Quick Guide
Voltage (V)
3 x 200
3 x 200
3 x 400
3 x 400
3 x 600
3 x 600
3.
Power
3 x 380-480 V
0.37-1.5 kW/0.5-2 Hp
2.2-4 kW/3-5.4 Hp
5.5-7.5 kW/7.5-10 Hp
11-15 kW/15-20 Hp
18.5-22 kW/25-30 Hp
30-45 kW/40-60 Hp
55-75 kW/100-120 Hp
90 kW/125 Hp
®
is a registered Danfoss trademark
Power range (kW)
0.25 – 3.7
5.5 – 45
0.37 – 7.5
11 – 90
2.2 – 7.5
11 – 90
Remove motor cable
3 x 525-600 V
22-30 kW/30-40 Hp
45-55ø W/60-100 Hp
75-90 kW/120-125 Hp
2.2-7.5 kW/3-10 Hp
11-15 kW/15-20 Hp
Min. waiting time
(minutes)
4
15
4
15
4
15
Clearance above/
below (mm/inch)
100/4
100/4
100/4
100/4
100/4
200/7.9
200/7.9
225/8.9
100/4
200/7.9
