Quick Guide
The FC101 Start-up Wizard for Open Loop Applications
No & Name Range
0-03 Regional Settings [0] International
[1] US
0-06 Grid Type [0] 200-240 V/50 Hz/IT-grid
[1] 200-240 V/50 Hz/Delta
[2] 200-240 V/50 Hz
[10] 380-440 V/50 Hz/IT-grid
[11] 380-440 V/50 Hz/Delta
[12] 380-440 V/50 Hz
[20] 440-480 V/50 Hz/IT-grid
[21] 440-480 V/50 Hz/Delta
[22] 440-480 V/50 Hz
[30] 525-600 V/50 Hz/IT-grid
[31] 525-600 V/50 Hz/Delta
[32] 525-600 V/50 Hz
[100] 200-240 V/60 Hz/IT-grid
[101] 200-240 V/60 Hz/Delta
[102] 200-240 V/60 Hz
[110] 380-440 V/60 Hz/IT-grid
[111] 380-440 V/60 Hz/Delta
[112] 380-440 V/60 Hz
[120] 440-480 V/60 Hz/IT-grid
[121] 440-480 V/60 Hz/Delta
[122] 440-480 V/60 Hz
[130] 525-600 V/60 Hz/IT-grid
[131] 525-600 V/60 Hz/Delta
[132] 525-600 V/60 Hz
1-20 Motor Power 0.12-110 kW/0.16-150 hp
1-22 Motor Voltage 50.0 - 1000.0 V
1-23 Motor Frequency 20.0 - 400.0 Hz
1-24 Motor Current 0.01 - 10000.00 A
1-25 Motor Nominal 100.0 - 9999.0 RPM
Speed
4-12 Motor Speed Low 0.0 - 400 Hz
Limit [Hz]
4-14 Motor Speed High 0.0 - 400 Hz
Limit [Hz]
3-41 Ramp 1 Ramp up 0.05 - 3600.0 s
Time
3-42 Ramp 1 Ramp 0.05 - 3600.0 s
Down Time
1-73 Flying Start [0] Disabled
[1] Enabled
6-19 Terminal 53 mode [0] Current
[1] Voltage
6-10 Terminal 53 Low 0-10 V
Voltage
6-11 Terminal 53 High 0-10 V
Voltage
6-12 Terminal 53 Low 0-20 mA
Current
6-13 Terminal 53 High 0-20 mA
Current
3-02 Minimum Reference -4999-4999
VLT HVAC Basic Drive Quick Guide
Default
0
Size related
Size related
Size related
Size related
Size related
Size related
0 Hz
65 Hz
Size related
Size related
0
1
0.07 V
10 V
4
20
0
®
MG18A302 - VLT is a registered Danfoss trademark
Function
Select operating mode for restart upon
reconnection of the drive to mains voltage after
power down
Enter motor power from nameplate data
Enter motor voltage from nameplate data
Enter motor frequency from nameplate data
Enter motor current from nameplate data
Enter motor nominal speed from nameplate data
Enter the minimum limit for low speed
Enter the maximum limit for high speed
Ramp up time from 0 to rated 1-23 Motor
Frequency
Ramp down time from rated 1-23 Motor Frequency
to 0
Select Enable to enable the frequency converter to
catch a spinning motor i.e. fan applications
Select if terminal 53 is used for current- or voltage
input
Enter the voltage that corresponds to the low
reference value
Enter the voltage that corresponds to the high
reference value
Enter the current that corresponds to the low
reference value
Enter the current that corresponds to the high
reference value
The minimum reference is the lowest value
obtainable by summing all references
