Quick Guide
1
1
I2 Frame
IP54 380-480 V 0.75-4.0 kW
1
2
3
1
RS 485
2
Line in
3
Earth
4
Wire clamps
5
Motor
6
UDC
7
Relays
8
I/O
12
VLT HVAC Basic Drive Quick Guide
I3 Frame
IP54 380-480 V 5.5-7.5 kW
8
7
6
5
4
1
2
3
4
5
6
7
8
®
MG18A302 - VLT
is a registered Danfoss trademark
RS 485
Line in
Earth
Wire clamps
Motor
UDC
Relays
I/O
