Victron energy Quattro 48/5000/70 Manual

Hide thumbs Also See for Quattro 48/5000/70:
Table of Contents

Advertisement

Quick Links

See also: User Manual and Installation Instructions
Manual
Quattro
12 | 5000 | 200 | 2x60 | 120/240V
24 | 5000 | 120 | 2x60 | 120/240V
48 | 5000 | 70 | 2x60 | 120/240V

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Quattro 48/5000/70 and is the answer not in the manual?

Questions and answers

Related Manuals for Victron energy Quattro 48/5000/70

Summary of Contents for Victron energy Quattro 48/5000/70

  • Page 1 Manual Quattro 12 | 5000 | 200 | 2x60 | 120/240V 24 | 5000 | 120 | 2x60 | 120/240V 48 | 5000 | 70 | 2x60 | 120/240V...
  • Page 3 EXCEED THE PURCHASE PRICE OF THE VICTRON ENERGY PRODUCTS DESCRIBED HERE IN. Victron Energy B.V. reserves the right to revise and improve its products as it sees fit. This publication describes the state of this product at the time of its publication and may...

  • Page 5: Safety Instructions

    1. SAFETY INSTRUCTIONS In general Please read the documentation supplied with this product first, so that you are familiar with the safety signs en directions before using the product. This product is designed and tested in accordance with international standards. The equipment should be used for the designated application only. WARNING: DANGER OF ELECTRICAL SHOCK The product is used in combination with a permanent energy source (battery).

  • Page 6: Transport And Storage

    Install the product in a heatproof environment. Ensure therefore that there are no chemicals, plastic parts, curtains or other textiles, etc. in the immediate vicinity of the equipment. Transport and storage On storage or transport of the product, ensure that the mains supply and battery leads are disconnected.
  • Page 7 2. DESCRIPTION 2.1 In general Two AC inputs with integrated transfer switch The Quattro can be connected to two independent AC sources, for example shore-side (grid-) power and a generator, or two generators. The Quattro will automatically connect to the active source. Figure 1: Block diagram Accepts several input voltages (See fig 1) Each AC input can be supplied from:...
  • Page 8 The AC inputs can be connected to a different type of supply: one input may for example be connected to a split phase source, and the other to a single phase source. When an AC source is available, the Quattro will feed through the AC to its output.
  • Page 9 When AC is present on one of the inputs, the inverter/charger of the Quattro connects to the preferred input leg (L1-1 or L1-2). PowerControl will therefore be active on the preferred input leg only. L1-1 of input AC-in-1, to which usually a generating set is connected, ─...

  • Page 10: Battery Charger

    More on batteries and charging Our book ‘Energy Unlimited’ offers further information on batteries and battery charging, and is available free of charge at Victron Energy (see www.victronenergy.com ). For more information on adaptive charging characteristics, please refer to the ‘Tech Info’ page on our website...
  • Page 11 2.3 Overview of AC power options Option 1 (see fig 1) As explained in section 2.1, the 120/240V Quattro can be connected to the standard American single phase and split phase AC supplies. When in inverter mode, however, the two live outputs are connected together to provide in phase 120 VAC on both lines.
  • Page 12 input. When operating from battery, the output will either be 120/240V or 120/208V depending on whether the system has been configured to operate with a 180 degrees or a 120 degrees phase shift. If only one 120V leg is available at the AC input, one unit will connect to it, and the other unit will operate on battery power.
  • Page 13 Figure 2a: Two stacked 120/240V Quattro’s (option 2a) Ground cables and interconnection for synchronization not shown Connection to second AC source not shown.
  • Page 14 Option 2b: Two stacked 120V or 120/240V Quattro’s or Multi’s with additional 120/240V input autotransformer AC source (input) Does system Power for Output connect to AC battery source? charging taken from 120/240V 3wire + Yes (neutral wire 240V 120/240V 3wire + ground should not be ground 60Hz...
  • Page 15 Figure 2b: Two stacked 120/240V Quattro’s with input autotransformer (option 2b) Ground cables and interconnection for synchronization not shown Connection to second AC source not shown.
  • Page 16 120/240V auto transformer when operating on battery. Victron Energy does provide 120/240V autotransformers with in-built neutral to ground relay. Advantages of this configuration: Only one inverter/charger needed.
  • Page 17 Figure 3: ‘European’ Quattro or Multi with additional 120/240V output autotransformer (option 3) Ground cables and not shown Connection to second AC source not shown.

  • Page 18: Remote Control

    3. Operation 3.1 “On / stand by / charger only” switch When the switch is switched to “on”, full device operation is initiated. The inverter will turn on, and the “inverter on” LED will light. 120VAC applied to L1-1 or L1-2 (see fig 1) will be switched through to the AC output connection.
  • Page 19 NOTE: Switching from “on” to “charger only” and vice versa, as described below, must be done quickly. The switch must be toggled such that the intermediate position is 'skipped', as it were. If the switch remains in the “off” position even for a short time, the device may be turned off. In that case, the procedure must be restarted at step 1.
  • Page 20 3.4 LED indications and their meaning LED off LED flashes LED lights Inverter charger inverter mains on inverter on The inverter is on, and bulk overload supplies power to the load. absorption low battery charger float only temperature charger inverter mains on inverter on The nominal power of...
  • Page 21 charger inverter mains on inverter on bulk overload The battery is almost empty. absorption low battery charger only float temperature charger inverter mains on inverter on bulk overload The inverter is switched off due to low battery voltage. absorption low battery charger float only...
  • Page 22 charger inverter – If the LEDs flash alternately, the battery mains on inverter on almost empty and nominal power is bulk overload exceeded. – If “overload” and “low battery” flash absorption low battery simultaneously, there is charger an excessively high only ripple voltage at the float...
  • Page 23 charger inverter mains on inverter on The AC voltage on AC- in-1 or AC-in-2 is switched bulk overload through, and the charger operates in absorption low battery absorption phase. charger only float temperature charger inverter mains on inverter on The AC voltage on AC- in-1 or bulk overload...
  • Page 24 Special indications Set with limited input current charger inverter The AC voltage on mains on inverter on AC1-in-1 or AC-in-2 is switched bulk overload through. The AC-input current is equal to the load current. The absorption low battery charger is down- charger controlled to 0A.
  • Page 25 4. Installation This product may only be installed by a qualified electrical engineer. 4.1 Contents of the box The Quattro box contains the following: Quattro inverter/battery charger • Manual • Suspension bracket • Temperature sensor • Warning sticker for battery charging •...
  • Page 26 Install the product in a heatproof environment. Ensure therefore that there are no chemicals, plastic parts, curtains or other textiles, etc. in the direct vicinity. The Quattro has no internal DC fuse. The DC fuse should be installed outside the Quattro. 4.3 Requirements A crosshead (Phillips) screwdriver (PH 2) for removing the front panel.

  • Page 27: Connecting The Battery Cables

    4.4 Connecting the battery cables In order to use the full potential of the Quattro, batteries of sufficient capacity and battery cables with the correct cross-section should be used. See table: Model 12/5000/200 24/5000/120 48/5000/70 Recommended battery capacity 800–2400 400–1400 200–800 (Ah) Recommended DC fuse...
  • Page 28 The Quattro is provided with a ground relay (see fig 1)) that automatically connects the N output to the casing if no external AC supply is available. If an external AC supply is provided, the ground relay H will open before the input safety relay closes (relay R1 or R2).
  • Page 29 cross-section must be sized accordingly. The L2 output should be limited to 60A or less. Procedure The connection terminals: PE: earth N: neutral conductor L1, L2: phase/live conductors 4.6 Connection options 4.6.1 Starter battery (connection terminal G, see appendix A) The Quattro has a connection for charging a starter battery.
  • Page 30 In the event of connecting Quattro units in parallel, the following requirements must be met: A maximum of six units connected in parallel. • Only identical devices with the same power ratings may be connected in • parallel. Battery capacity should be sufficient. •...
  • Page 31 5. Configuration Settings may only be changed by a qualified electrical • engineer. Read the instructions thoroughly before implementing • changes. During setting of the charger, the DC fuse in the battery • connections must be removed. 5.1 Standard settings: ready for use On delivery, the Quattro is set to standard factory values.
  • Page 32 VirtualSwitch controls the multi- functional relay PowerAssist 5.2 Explanation of settings Settings that are not self-explanatory are described briefly below. For further information, please refer to the help files in the software configuration programs (see Section 5.3). Inverter frequency Output frequency if no AC is present at the input. Adjustability: 60Hz;...
  • Page 33 Ground relay (see appendix B) With this relay (H), the neutral conductor of the AC output is grounded to the casing when the back feed safety relays in the AC-in-1 and the AC-in-2 inputs are open. This ensures the correct operation of earth leakage circuit breakers in the outputs.
  • Page 34 Generator (AC-in-1) / Shore current (AC-in-2) These are the standard current limit settings at which PowerControl and PowerAssist come into operation. See Section 2, the book 'Energy Unlimited', or the many descriptions of this unique feature on our website www.victronenergy.com UPS mode If this setting is ‘on’...
  • Page 35 BoostFactor Change this setting only after consulting with Victron Energy or with an engineer trained by Victron Energy! Not adjustable with DIP switches. Multi-functional relay By default, the multi-functional relay is set as an alarm relay, i.e. the relay will de-energise in the event of an alarm or a pre-alarm (inverter almost too hot, ripple on the input almost too high, battery voltage almost too low).
  • Page 36 If your computer does not have a RS232 connection but is equipped with USB, you will also need a RS232-to-USB interface cable. Both are available from Victron Energy. 5.4 Implementing settings with a VE.Net panel To this end, a VE.Net panel and the VE.Net to VE.Bus converter is required.
  • Page 37 5.5 Configuration with DIP switches Introduction A number of settings can be changed using DIP switches (see appendix A, position M). This is done as follows: Turn the Quattro on, preferably unloaded and without AC voltage on the inputs. The Quattro will then operate in inverter mode. Step 1: Setting the DIP switches for: - the required current limitation of the AC inputs.
  • Page 38 Procedure: set the DIP switches to the required value: ds8 ds7 ds6 off = 15A (1.8kVA at 120V) on = 20A (2.4kVA at 120V) off = 25A (3.0kVA at 120V) on = 30A (3.6kVA at 120V) off = 35A (4.2kVA at 120V) on = 40A (4.8kVA at 120V) off = 50A (6.0kVA at 120V) on = 60A (7.2kVA at 120V)
  • Page 39 NOTE: When configuring a parallel or 2-3 phase system, all related • devices should be interconnected using RJ45 UTP cables (see appendix C, D). All devices must be turned on. They will subsequently return an error code (see Section 7), since they have been integrated into a system and still are configured as ‘stand- alone’.
  • Page 40 Stand-alone operation (see figure 1) Step 1: Setting ds2 and ds1 for stand-alone operation DS-8 AC-in-1 Set as desired DS-7 AC-in-1 Set as desired DS-6 AC-in-1 Set as desired DS-5 AC-in-2 Set as desired DS-4 Charging current Set as desired DS-3 Charging current Set as desired DS-2 Stand-alone operation DS-1 Stand-alone operation...
  • Page 41 Parallel operation (see appendix C) Step 1: Setting ds2 and ds1 for parallel operation of two or three units Master Slave 1 Slave 2 (optional) DS-8 AC-in-1 DS-8 na DS-8 na DS-7 AC-in-1 DS-7 na DS-7 na DS-6 AC-in-1 DS-6 na DS-6 na DS-5 AC-in-2 DS-5 na...
  • Page 42 The settings according to this example (15kVA parallel system) are as follows: Master Slave 1 Slave 2 DS-8 AC-in-1 (3 x 35 = 105A) DS-8 na DS-8 na DS-7 AC-in-1 (3 x 35 = 105A) DS-7 na DS-7 na DS-6 AC-in-1 (3 x 35 = 105A) DS-6 na DS-6 na DS-5 AC-in-2 na (30A panel)
  • Page 43 Example: AC-in-1 current limitation on the leader and the followers: 30A (setting for generator power 30 x 120 x 2 = 7kVA). AC-in-2 current limitation with 30A panel. If the charging current on the leader is set to 100% (120A for a Quattro 24/5000/120) and the system consists of two devices, then the effective system charging current is equal to 2 x 120 = 240A.
  • Page 44 Three phase operation (see appendix D) Step 1: Setting ds2 and ds1 for 3-phase operation Leader (L1) Follower (L2) Follower (L3) DS-8 AC-in-1 DS-8 Set DS-8 Set DS-7 AC-in-1 DS-7 Set DS-7 Set DS-6 AC-in-1 DS-6 Set DS-6 Set DS-5 AC-in-2 DS-5 Set DS-5 Set DS-4 Ch.
  • Page 45 To store the settings after the required values have been set: press the 'Up' button of the leader for 2 seconds (upper button to the right of the DIP switches, see appendix A, position K). The overload and low-battery LED’s will flash to indicate acceptance of the settings.
  • Page 46 ds6: absorption time 8 or 4 hours on = 8 hours off = 4 hours (not relevant for L2, L3) ds5: adaptive charging characteristic on = active off = inactive (fixed absorption time) (not relevant for L2, L3) ds4: dynamic current limiter on = active off = inactive ds3: UPS function...
  • Page 47 Step 2: Exemplary setting for parallel mode In this example, the master is configured according to factory settings. The slaves do not require setting! Master Slave 1 Slave 2 DS-8 Ch. voltage(GEL 14,4V) DS-8 na DS-8 na DS-7 Ch. voltage(GEL 14,4V) DS-7 na DS-7 na DS-6 Absorption time (8 h)
  • Page 48 To store the settings after the required values have been set: press the 'Down' button of the leader for 2 seconds (lower button to the right of the DIP switches). The temperature and low-battery LEDs will flash to indicate acceptance of the settings. You can then leave the DIP switches in the selected positions, so that the ’other settings’...
  • Page 49 7 Error indications With the procedures below, most errors can be quickly identified. If an error cannot be resolved, please refer to your Victron Energy supplier. 7.1 General error indications Problem Cause Solution No output voltage Quattro in inverter mode...
  • Page 50 The charger does not The AC input voltage or frequency Ensure that the AC input is operate. is not within the range set. between 185 VAC and 265 VAC, and that the frequency is within the range set (default setting 45- 65Hz).
  • Page 51 7.2 Special LED indications (for the normal LED indications, see section 3.4) Bulk and absorption LEDs flash Voltage sense error. The voltage synchronously (simultaneously). measured at the voltage sense connection deviates too much (more than 7V) from the voltage on the positive and negative connection of the device.
  • Page 52 A flashing "overload" LED indicates that the device can perform • inverter operation. A flashing "temperature" LED indicates that the device is not • blocking charging operation. NOTE: In principle, all other LEDs must be off. If this is not the case, the code is not an OK code.
  • Page 53 Code Meaning: Cause/solution: Device is switched off because Check the failing phase. one of the other phases in the system has switched off. Not all, or more than, the expected The system is not properly configured. devices were found in the system. Reconfigure the system.

  • Page 54: Technical Specifications

    8. Technical specifications Quattro 12/5000/200 24/5000/120 48/5000/70 120/240V 120/240V 120/240V PowerControl / PowerAssist Integrated Transfer switch Input voltage: 120 V or 120/240 V Input frequency: 45 – 65 Hz AC inputs (2x) Power factor: 1 120V single phase: 60 A 120V dual in phase: 60 A total AC feed through capacity (A) 120/240 V split phase: 60 A each leg INVERTER...
  • Page 55 APPENDIX A: Connection overview...
  • Page 56 APPENDIX A: Connection overview AC input (generator input) AC-in-1. Left to right: L (phase), N (neutral), PE (ground). 2x RJ45 connector for remote panel and/or parallel and 3-phase operation. AC output AC-out-1. Left to right: L (phase), N (neutral), PE (ground).
  • Page 57 APPENDIX B: Block diagram Isolation transformer (recommended on boats) on AC input . Install a GFCI (ground fault circuit interrupter) on AC output. Ground in and output connected to chassis. Back feed safety relay. Ground relay (closed when back feed is open) Always install a DC fuse.
  • Page 58 APPENDIX C: Parallel connection...
  • Page 59 APPENDIX D: Three-phase connection...
  • Page 60 APPENDIX E: Charge characteristics C h a rg e c u r re n t 1 2 0 % 1 0 0 % 8 0 % A m p s 6 0 % 4 0 % 2 0 % T i m e V o l ts C h a rg e v o lta g e T i m e...
  • Page 61 APPENDIX F: Temperature compensation 15.0 14.5 14.0 13.5 13.0 Volts 12.5 Volts 12.0 11.5 11.0 10.5 10.0 10 15 20 25 30 35 40 45 50 55 60 Battery temperature Default output voltages for Float and Absorption are at 25° C. Reduced Float voltage follows Float voltage and Raised Absorption voltage follows Absorption voltage.
  • Page 62 APPENDIX G: Dimensions...
  • Page 64 Distributor: Serial number: Version : 01 Date : 14 August 2008 Victron Energy B.V. De Paal 35 | 1351 JG Almere PO Box 50016 | 1305 AA Almere | The Netherlands General phone : +31 (0)36 535 97 00 Customer support desk...
