Oximo 50 S auto RTS

6.2 Controlling the direction of rotation

Press the up button on the RTS control point:
1)
If the roller shutter is raised, the direction of
a)
rotation is correct:
Go to paragraph entitled "Confirming the
automatic settings".
If the roller shutter is lowered, the direction of
b)
rotation is incorrect:
Move onto the next step.
Press the RTS control point STOP/my button
2)
until the roller shutter makes an up and down
movement:
The direction of rotation has been modified.
Press the RTS control point Up button to check
3)
the direction of rotation.
6.3 Confirming the automatic settings
Press the up and down buttons until the roller shut-
1)
ter moves up and down.
Press the STOP/my button until the roller shutter
2)
moves up and down.
The end
programmed.
Press the RTS control point PROG button to
3)
program the first control point:
The roller shutter moves up and down.

7. Optional specific settings

7.1 Favourite position

7.1.1 Definition
The Oximo 50 S auto RTS motor is supplied with
a pre-programmed favourite position which corres-
ponds to almost complete closure of the roller shut-
ter (slats in sun protection position).
7.1.2 Activating the favourite position
Carry out 2 complete roller shutter up and down
-
cycles up to the upper and lower end limits to
activate the favourite position.
7.1.3 Modifying the favourite position
Place the roller shutter into the required new
1)
favourite position (my) by pressing the up or
down button on the RTS control point.
Press the STOP/my button until the roller shutter
2)
moves up and down:
The new favourite position has been
programmed.
56
limit positions
1
2
1
have been
3
PROG.
1
or
Copyright © 2008 Somfy SAS. All rights reserved.
Installation guide
Confirming
a
the settings
Move
b
onto the next step
3
2
2
my
