Allusion Slim Series:
Models:
SF-ALLS40
SF-ALLS50
SF-ALLS60
SF-ALLS72
• Important operating
a n d m a i n t e n a n c e
instructions included.
Congratulations!
Congratulations on selecting a SimpliFire Electric Fireplace, an elegant and clean alternative to wood & gas burning fireplaces.
The SimpliFire electric fireplace you have selected is designed to provide the utmost in safety, reliability, and efficiency.
READ CAREFULLY BEFORE ATTEMPTING TO ASSEMBLE, INSTALL, OPERATE, OR MAINTAIN
THIS PRODUCT.
PROTECT YOURSELF AND OTHERS BY OBSERVING ALL SAFETY INFORMATION. FAILURE
TO COMPLY WITH INSTRUCTIONS COULD RESULT IN PERSONAL INJURY AND/OR
PROPERTY DAMAGE.
WARNING: To reduce risk of fire, electrical shock, or personal injury, read all instructions
before using appliance.
SimpliFire • SF-ALLS40, SF-ALLS50, SF-ALLS60, SF-ALLS72 • SF-ALLS-MAN Rev. C • 9/24
NOTICE
DO NOT DISCARD THIS MANUAL
• Read, understand and follow
these instructions for safe
installation and operation.
SimpliFire, a brand of Hearth & Home Technologies
7571 215
Street West, Lakeville, MN 55044
th
www.hearthnhome.com
Owner's Manual
Installation and Operation
• Leave this manual with
party responsible for use
and operation.
