SimpliFire SF-ALL60-BK Instructions

Leave this instruction with party responsible for
use and operation.
NOTICE! DO NOT discard these instructions.
service and maintenance instructions included.
NOTICE! DO NOT discard any hardware while
servicing. It may be reused.
CAUTION! Risk of Cuts, Abrasions or Flying Debris.
Wear protective gloves and safety glasses during
installation and service. Sheet metal edges are sharp.
WARNING! Risk of Shock! Always unplug the cord or
turn off the circuit breaker before moving or servicing.

Tools and Supplies Needed

Before beginning the installation be sure that the following
tools - supplies are available.
Gloves
Magnetic Phillips screwdriver
Safety glasses
Crystal Media (included with appliance)
Kit includes:
LOG LOG
REFERENCE QUANTITY
LETTER
A
B
C
D
E
F
G
H
SF-MEDIA-LOGS
Model: SF-ALL48-BK, SF-ALL60-BK
Important
2
1
1
1
1
1
3
2
SimpliFire • SF-MEDIA-LOGS Instructions • 2040-935 • 3/18
Instructions
CAUTION! Two adults recommended for the removal
or installation of glass front. Use caution when han-
dling glass. Failure to do so could result in personal injury
or property damage.
Glass Front Removal
Remove Glass Front
1. Remove the two (2) ST3X8 screws located on the
glass panel. See Figure 1.
Note: Do not discard screws, screws will be reused.
2. Lift up evenly on the bottom edge of the glass to
disengage the J-hooks from the shoulder bolts on the
appliance.
Figure 1. Remove Glass Front
