Installing SoundPoint
This section provides basic installation
instructions and information for obtaining
the best performance with the SoundPoint
IP 600 SIP telephone. If you require
®
additional information or assistance with
your new telephone, please contact your
System Administrator.

Connecting Network and Power Source

AC Power Option
Connect the supplied Network cable
between the LAN jack on the telephone
and the LAN port on the wall or hub/switch
device port. Connect the DC plug on the
AC wall adapter to the DC jack marked on
the telephone.
In-Line Power Option
If the telephone is connected to a compatible
Ethernet switch that can provide in-line
power, the telephone will use that power
option. Simply plug the supplied Net-
work cable between the LAN jack on the
telephone and an available Power and Data
port on the In-Line Power switch.
IP 600 SIP
®
The SoundPoint
includes regulatory compliance infor-
mation that your System Administrator
should review and can also be found at
http://www.polycom.com.
Cisco™ Catalyst™ In-Line
Power Switch
IEEE 802.3af compliant
In-Line Power switch
2
IP 600 SIP User Guide
®
(Optional)
