Pro-Form XP 185 U User Manual page 10

11. Identify the Right Pedal (26), which is marked
with an "R."
Using an adjustable wrench, firmly tighten the
Right Pedal (26) clockwise into the right arm of
the Crank (13).
Tighten the Left Pedal (not shown) counter-
clockwise into the left arm of the Crank.
IMPORTANT: Tighten both Pedals as firmly
as possible. After using the exercise bike for
one week, retighten the Pedals. For best per-
formance, keep the Pedals tightened.
Adjust the strap on the Right Pedal (26) to the
desired position, and press the end of the strap
onto the tab on the side of the Right Pedal.
Adjust the strap on the Left Pedal (not
shown) in the same way.
12. Make sure that all parts are properly tightened before you use the exercise bike. Note: After assembly is
completed, some extra parts may be left over. Place a mat beneath the exercise bike to protect the floor.
All manuals and user guides at all-guides.com
10
11
13
Strap
26
Tab
