- Page 1 FZR 2046 E...
-
Page 2: Table Of Contents
Table of contents Electric Lawn mower USER MANUAL Thank you for purchasing this rotary electric lawn mower. Before you start using it, please read this user manual carefully and save it for future use. TABLE OF CONTENTS 1. GENERAL SAFETY REGULATIONS ..........................4 Important safety notice ............................4 Packaging ..................................4 User manual ...................................4... -
Page 3: General Safety Regulations
User manual. The User manual also contains operating, maintenance, and repair instructions. The manufacturer takes no responsibility for accidents or damages from not following the instructions in this manual. FZR 2046 E... -
Page 4: Symbols
Symbols 2. SYMBOLS Read the manual with the instructions before using this machine. Bystanders must be at a safe distance. Be careful of the sharp blade edges. The blades continue to rotate even after the motor is turned off. Before carrying out maintenance or if the power cable is damaged, disconnect the plug from the mains. -
Page 5: Description (Fig. 1.)
3. Top part of the handle 4. Handle fast clamp 5. Bottom part of the handle 6. Transport handle 7. Mowing height adjustment lever 8. Start/stop trigger safety lock 9. Grass catcher cover/rear defl ector PIC. 1 FZR 2046 E... -
Page 6: Basic Work Safety
Basic work safety 4. BASIC WORK SAFETY Never use the machine if the power cable is damaged or visibly worn. If the lawnmower is connected to a power source using a damaged power cable and the place that is not insulated is touched before the lawnmower is disconnected from the power source, you risk being electrocuted. -
Page 7: Before You Start Using The Lawn Mower
The following general rules apply for work with the lawn mower: When mowing on a slope, do not move up and down but always along the contours, i.e. horizontally perpendicular to the incline of the slope. Be very careful when changing direction on a slope. Never use the lawn mower on extremely steep slopes. FZR 2046 E... -
Page 8: Maintenance And Storage
Basic work safety If you need to pull the lawnmower towards you while it is running or if you need to move backwards with the lawnmower, be very careful. Always stop the blades from turning when transporting the machine or moving over an un-grassed area. Never use the machine if any covers are damaged or if any of its safety elements are missing such as defl... -
Page 9: Assembly
• Do not over-tighten the quick clamping nuts. The handle must not move and the lever must be easy to release. • When the fast clamping levers are released, the handle can be folded for transporting or storing the mower. Fig. 2a Fig. 2b Fig. 2c FZR 2046 E... -
Page 10: Assembling And Mounting The Grass Catcher
Assembly 5.2 ASSEMBLING AND MOUNTING THE GRASS CATCHER. PIC. 3a Insert the handle into the grass catcher cover. See Fig. 3a. Fix the frame to the upper plastic cover with the 4 attached bolts and washers. 3b. Mount textile part on the cap of catcher and the frame. Fig 3c. Fitting the grass catcher: Lift the rear cover, see Fig. -
Page 11: Operation
Release the switching lever, see Fig. 5, point 2 ATTENTION: The blade will rotate for several seconds after the lawn mower is turned off. ATTENTION: Do not turn the lawn mower off and on in quick succession. FZR 2046 E... -
Page 12: Technical Specifications
Technical specifi cations 7. TECHNICAL SPECIFICATIONS Model FZR 2046 E Power source 230-240 V, 50 Hz Power input 2000 W Idling speed 3300 rpm Coverage width (blade length): 430 mm Mowing heights 20-70 mm (6 positions) Grass catcher volume 50 l Weight when empty: 15.40 Kg... -
Page 13: Troubleshooting
Repair the mower before starting it again. If the vibrations continue, call the free client line. The blade is not balanced. Balance the blade evenly by grinding each cutting edge. FZR 2046 E... -
Page 14: Maintenance
Before using the machine, carry out all necessary repairs and maintenance. If, despite regular maintenance, the machine does not work, please contact our customer service, the repair should be carried out by our contractual partner in one of the specialised Fieldmann workshops. 9.1 BLADE REPLACEMENT Contact an authorised service centre. -
Page 15: Disposal
This appliance meets all the basic requirements of the EU directives. The text, design and technical specifi cations can be changed without prior notice and we reserve the right to make these changes. User manual in the original language. FZR 2046 E... - Page 18 A FAST Hungary Kft. (2310, Szigetszentmiklós, Kántor u. 10) mint a termék magyarországi im- portőrea jótállási jegyen feltüntetett típusú és gyár- tási számú készülékre jótállást biztosít a fogyasztók számára az alábbi feltételek szerint: 2310, Szigetszentmiklós Kántor u. 10...
