Specifications: Item Specification Details Enclosure Steel IP30 Dimensions H x W x D mm 320 x 345 x 88 Weight (excluding batteries) Temperature -5°C to 40°C Humidity 95 % Max Cable Entries (20mm knockouts) 7x top and 7x top rear Mains Supply 230V +10%, -15%, 50/60Hz AC, 0.4A max Battery Capacity...
1 Introduction 1.1 Standards Advanced Electronics Ltd declares that the Mx-4100S meets the CE requirements of the following EU Directives: Low Voltage Directive 2006/95/EC EN60950-1: 2006 Safety of information technology equipment Electromagnetic Compatibility Directive 2004/108/EC EN61000-6-3:2001 Emissions, Class B EN50130-4: 1995 +A1:1998 +A2: 2003...
1.1 Installation Approvals 1.1.1 Fire System Installations The panel must be installed and configured for operation in accordance with these instructions and the applicable code of practice or national standard regulations for fire systems installation (for example BS5839-1: 2002) appropriate to the country and location of the installation. 1.1.2 Wiring Regulations The panel and system must be installed in accordance with these instructions and the applicable wiring codes and regulations (for example BS7671) appropriate to the country and location of the installation.
2 Installation 2.1 Identification of Parts The following diagrams show the major parts of the panels. Chassis Assembly Earth Lead to Cover Rear Enclosure AC Mains Battery Input Leads 2.2 Installing the Enclosure The panel can weigh in excess of 15kg when the batteries are installed. Use the appropriate fixing hardware to secure the panel to the wall.
2.2.3 Mounting the Enclosure Firstly, remove the required knockouts for the installation wiring. There are sufficient knockouts on the top of the enclosure for all installation wiring. In addition, there are knockouts at the top of the back wall, if required, for rear entry cabling.
2.3 Battery Installation The diagram opposite shows the recommended location and orientation for the 7AH batteries within the panel. For battery sizes greater than 7AH, the batteries must be installed in a separate enclosure suitable for fire protection use with wiring connected to the panel through rigid conduit.
3 Programming 3.1 Introduction Full instructions for the configuration and programming of the Mx-4000 Series panels are detailed in Manual 680-014. The following details the features not included in the Mx-4100S panel by menu option. VIEW The View – Network option is not available. SETUP The network options (This Network Node and Next Network Node) are not available.
Page 10
This page is intentionally left blank. www.advancedco.com...
