R82 Multi Frame:x User Manual page 27

mm (inch)
Base plate (width x depth)
Overall width
Width between wheels
Length
Folded length
Overall height
Back height
Seat surface height at front edge
Footrest to adaptor plate
Seat plane angle
Back angle
Total mass
Max load
Max load at transportation
Static stability downhill
Static stability uphill
Static stability sideways
support.R82.org
3
215 x 405 mm (8½" x 16")
660 mm (26")
535 mm (21")
840 mm (33")
840 mm (33")
980 mm (38½")
570 mm (22½")
410 / 435 / 460 mm (16¼" / 17¼" / 18")
260 - 430 mm (10¼ - 17")
-5° -> 30°
0 - 30°
20 kg (44 lb)
100 kg (220.4 lb)
100 kg (220.4 lb)
>10°
>10°
>10°
