ElEctric chainsaw
sEt up and OpErating instructiOns
Diagrams within this manual may not be drawn proportionally.
Due to continuing improvements, actual product may differ slightly from the product described herein.
distributed exclusively by harbor Freight tools
Visit our website at: http://www.harborfreight.com
read this material before using this product.
Failure to do so can result in serious injury.
saVE this Manual.
Copyright
2006 by Harbor Freight Tools
©
manual or any artwork contained herein may be reproduced in any shape or form
without the express written consent of Harbor Freight Tools.
For technical questions or replacement parts, please call 1-800-444-3353.
sharpEnEr
Model
3491 Mission Oaks Blvd., Camarillo, CA 93011
95313
. All rights reserved. No portion of this
®
.
®
cover revised 07l
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Chicago Electric 95313
Summary of Contents for Chicago Electric 95313
-
Page 1: Set Up And Operating Instructions
ElEctric chainsaw sharpEnEr Model 95313 sEt up and OpErating instructiOns Diagrams within this manual may not be drawn proportionally. Due to continuing improvements, actual product may differ slightly from the product described herein. distributed exclusively by harbor Freight tools ®... -
Page 2: Specifications
Never allow children to hol, or medication. A moment of inatten- handle this product. tion while operating power tools may result in serious personal injury. rEV 07l SKU 95313 For technical questions, please call 1-800-444-3353 Page 2... -
Page 3: Tool Use And Care
(9). Hand tighten it only. Overtightening may Maintain tools with care. Keep cutting cause the wheel to break or disintegrate. tools maintained and clean. Properly rEV 07l SKU 95313 For technical questions, please call 1-800-444-3353 Page 3... -
Page 4: Grounded Tools: Tools With Three Prong Plugs
“live” terminal. (see 3-prong plug and Outlet.) rEV 07l SKU 95313 For technical questions, please call 1-800-444-3353 Page 4... -
Page 5: Double Insulated Tools: Tools With Two Prong Plugs
For example, a 14 gauge cord can carry a higher current than a 16 gauge cord. (see table a.) When using more than one extension cord to make up the total length, make sure each SKU 95313 For technical questions, please call 1-800-444-3353 Page 5... - Page 6 Double Insulated Canadian Standards Association Underwriters Laboratories, Inc. Volts Alternating Current Amperes No Load Revolutions per Minute n 0 xxxx/min. (RPM) SKU 95313 For technical questions, please call 1-800-444-3353 Page 6...
-
Page 7: Assembly And Operation
Raise the Top Housing (4) and lock it in the up position by tightening the Lock Stop (6) as in figure 3. See FIGURE 3. Remove the two screws holding the Grinding Wheel Cover (11). Set the cover aside. SKU 95313 For technical questions, please call 1-800-444-3353 Page 7... - Page 8 Over-sharpening can weaken the chain causing the possibility of chain breakage or other failure which can cause property damage or severe personal injury. SKU 95313 For technical questions, please call 1-800-444-3353 Page 8...
- Page 9 Reposition the Chain Stop and tighten the Handle. Turn the tool ON. Repeat the grinding operation. Continue in this manner until all teeth in the chain with the selected angle are sharpened. SKU 95313 For technical questions, please call 1-800-444-3353 Page 9...
- Page 10 Check the condition of the chain as you sharpen it. Twisted links must be repaired or the chain discarded. If the chain has been sharpened repeatedly, it will eventually be worn down and must be discarded. Never use a worn or damaged chain on any chainsaw. SKU 95313 For technical questions, please call 1-800-444-3353 Page 10...
-
Page 11: Parts List
Spring washer Bearing Swing Arm Pressure panel Chain Stop Screw Tension Spring nOtE: Some parts are listed and shown for illustration purposes only and are not available individually as replacement parts. SKU 95313 For technical questions, please call 1-800-444-3353 Page 11... -
Page 12: Assembly Drawing
SKU 95313 For technical questions, please call 1-800-444-3353 Page 12... -
Page 13: Limited 1 Year / 90 Day Warranty
ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACE- MENT PARTS THERETO. SKU 95313 For technical questions, please call 1-800-444-3353 Page 13...
