BREAKER HAMMER
ASSEMBLY AND OPERATING INSTRUCTIONS
Diagrams within this manual may not be drawn proportionally.
Due to continuing improvements, actual product may differ slightly from the product described herein.
Distributed exclusively by Harbor Freight Tools
Visit our website at: http://www.harborfreight.com
Read this material before using this product.
Failure to do so can result in serious injury.
SaVe THiS manual.
Copyright
2006 by Harbor Freight Tools
©
manual or any artwork contained herein may be reproduced in any shape or form
without the express written consent of Harbor Freight Tools.
For technical questions or replacement parts, please call 1-800-444-3353.
Model 94882
3491 Mission Oaks Blvd., Camarillo, CA 93011
. All rights reserved. No portion of this
®
.
®
Advertisement
Table of Contents
Related Manuals for Chicago Electric BREAKER HAMMER 94882
Summary of Contents for Chicago Electric BREAKER HAMMER 94882
- Page 1 BREAKER HAMMER ASSEMBLY AND OPERATING INSTRUCTIONS Diagrams within this manual may not be drawn proportionally. Due to continuing improvements, actual product may differ slightly from the product described herein. Distributed exclusively by Harbor Freight Tools 3491 Mission Oaks Blvd., Camarillo, CA 93011 Visit our website at: http://www.harborfreight.com Read this material before using this product.
-
Page 2: Product Specifications
Electrical Requirement Impactor Travel Overall Dimensions Blows per minute Retainer Style Retainer Capacity Bit hardness Bit Dimensions: Noise Level Impact Energy Tool Weight NOTE: Plug this tool into a 20 Amp. dedicated circuit. You will need this manual for the safety warnings and precautions, assembly, operating, inspection, maintenance and cleaning procedures, parts list and assembly diagram. -
Page 3: Electrical Safety
Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases, or dust. Power tools create sparks which may ignite the dust or fumes. Keep bystanders, children, and visitors away while operating a power tool. Distractions can cause you to lose control. - Page 4 Dress properly. Do not wear loose clothing or jewelry. Contain long hair. Keep your hair, clothing, and gloves away from moving parts. Loose clothes, jewelry, or long hair can be caught in moving parts. Avoid accidental starting. Be sure the Power Switch is off before plugging in.
-
Page 5: Grounded Tools: Tools With Three Prong Plugs
Tool service must be performed only by qualified repair personnel. Service or maintenance performed by unqualified personnel could result in a risk of injury. When servicing a tool, use only identical replacement parts. Follow instructions in the “Inspection, Maintenance, And Cleaning” section of this manual. Use of unauthorized parts or failure to follow maintenance instructions may create a risk of electric shock or injury. -
Page 6: Double Insulated Tools: Tools With Two Prong Plugs
FIGURE A DOUBLE INSULATED TOOLS: TOOLS WITH TWO PRONG PLUGS Tools marked “Double Insulated” do not require grounding. They have a special double insulation system which satisfies OSHA requirements and complies with the applicable standards of Underwriters Laboratories, Inc., the Canadian Standard Association, and the National Electrical Code. -
Page 7: Extension Cords
Grounded tools require a three wire extension cord. Double Insulated tools can use either a two or three wire extension cord. As the distance from the supply outlet increases, you must use a heavier gauge extension cord. Using extension cords with inadequately sized wire causes a serious drop in voltage, resulting in loss of power and possible tool damage. -
Page 8: Specific Safety Rules
Maintain labels and nameplates on the Breaker Hammer. These carry important information. If unreadable or missing, contact Harbor Freight Tools for a replacement. Industrial applications must follow OSHA requirements. Check for damaged parts. Before using this product, carefully check that it will operate properly and perform its intended function. -
Page 9: Vibration Hazard
WARNING! People with pacemakers should consult their physician(s) before using this product. Electromagnetic fields in close proximity to a heart pacemaker could cause interference to or failure of the pacemaker. WARNING: Always wear ANSI-approved impact safety goggles. Wear a full face shield if you are producing metal filings or wood chips. - Page 10 When unpacking, check to make sure all parts shown on the Parts Lists and Assembly Diagrams on pages 12-14 are included. If any parts are missing or broken, please call Harbor Freight Tools at the number shown on the cover of this manual as soon as possible. How to attach and adjust the Side Handle: Slide the Clamp (122) over the Collet (8).
-
Page 11: Important - Read Before Use
How to attach the chisels Slide the chisels into the Breaker Hammer with the flat cut-out side facing up and while the Rod (4) is aligned with the Chisel shank. See figure 2. The Chisel has a flat space on the shaft that must be turned horizontally when it is inserted. -
Page 12: Inspection, Maintenance, And Cleaning
OPERATING INSTRUCTIONS (CONTINUED) Chipping in a straight line with a chisel bit Use chalk or another suitable writing material and mark you work surface to delineate the area you intend to hammer. Plug in the Breaker Hammer. Grasp the main Handle (90) and side Handle (90) firmly with both hands. When you are sure that no people or animals are in the vicinity, and it’s safe to begin, depress the Switch (62). -
Page 13: Parts List
PART NAME Bushing Ring Screw M6X40 Washer Spring Washer Collet O Ring O Ring O Ring Spindle Cover Seal O Ring Rear Bushing Beat Piece Bushing Damper Bushing O Ring Seal O Ring O Ring Cylinder Sleeve O Ring Front Housing Spring Guide Spring Spring Guide... -
Page 14: Please Read The Following Carefully
PART NAME Bearing 600NSK Washer Magnetism Ring Rotor Screw ST5X70 Stator Housing Glass Fiberpipe Handle Screw M5X18 Washer Spring Washer Screw M4X12 Cord Clip Gear Case O Ring Bearing 6304NSK Crank Shaft 100 Cover 101 Spring Washer 102 Washer 103 Screw M5X22 104 Needle bearing PLEASE READ THE FOLLOWING CAREFULLY THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED... -
Page 15: Assembly Diagram
ASSEMBLY DIAGRAM SKU 94882 PAGE 15... -
Page 16: Limited 90-Day Warranty
LIMITED 90 DAY WARRANTY Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards, and warrants to the original purchaser that this product is free from defects in materials and workmanship for the period of 90 days from the date of purchase.
