Multi-purpose electric

set up and operating instructions

Visit our website at: http://www.harborfreight.com
read this material before using this product.
Failure to do so can result in serious injury.
saVe this Manual.
©
Copyright
2008 by Harbor Freight Tools
contained herein may be reproduced in any shape or form without the express written consent of Harbor
Freight Tools. Diagrams within this manual may not be drawn proportionally. Due to continuing improve-
ments, actual product may differ slightly from the product described herein. Tools required for assembly
and service may not be included.
For technical questions or replacement parts, please call 1-800-444-3353.
sharpener
Model
®
. All rights reserved. No portion of this manual or any artwork
99823
Manual revised 10e

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 99823 and is the answer not in the manual?

Questions and answers

Related Manuals for Chicago Electric 99823

Summary of Contents for Chicago Electric 99823

  • Page 1: Set Up And Operating Instructions

    Multi-purpose electric sharpener Model 99823 set up and operating instructions Visit our website at: http://www.harborfreight.com read this material before using this product. Failure to do so can result in serious injury. saVe this Manual. © ® Copyright 2008 by Harbor Freight Tools .

  • Page 2: Important Safety Instructions

    Keep the work area well lit. Make death or serious injury. sure there is adequate surrounding workspace. Keep the work area free of obstructions and other debris. SKU 99823 For technical questions, please call 1-800-444-3353. Page 2...

  • Page 3: Electrical Safety

    A short power supply cord is to be provided to reduce risks resulting from becoming entangled in or SKU 99823 For technical questions, please call 1-800-444-3353. Page 3...

  • Page 4: Specifications

    Specific Safety Rules grinding wheel Must Be rated to at least 4800 rpM. Wear ansi-approved safety goggles and heavy-duty work gloves during set up and use. REV 08k SKU 99823 For technical questions, please call 1-800-444-3353. Page 4...
  • Page 5 There are three sharpening channels on each side of the Motor Attachments for this Multi-purpose Housing. All three snap in place. Electric Sharpener: Figure 1 a. Standard Knife and Scissor Attachment. SKU 99823 For technical questions, please call 1-800-444-3353. Page 5...

  • Page 6: Operation

    Insert the bit into the Clamp and while pushing it into the “V”, rotate SKU 99823 For technical questions, please call 1-800-444-3353. Page 6...
  • Page 7 Insert the Locking Nut for Clamp Holder (18) with Top Lock Nut for Clamp Holder (19) into the slot of the Turn Nut for Clamp Holder (17); SKU 99823 For technical questions, please call 1-800-444-3353. Page 7...
  • Page 8 Attach the Scissors and Knife Sharpening Attachment to the grinding wheel side of the Motor Housing (1), making sure that the SKU 99823 For technical questions, please call 1-800-444-3353. Page 8...
  • Page 9 The magnet on the Support Plate will support the blade in position during set up, but the blade must be held firmly by hand during actual grinding. SKU 99823 For technical questions, please call 1-800-444-3353. Page 9...

  • Page 10: Inspection And Maintenance

    If product has no serial number, record month and year of purchase instead. note: Some parts are listed and shown for illustration purposes only, and are not available individually as replacement parts. SKU 99823 For technical questions, please call 1-800-444-3353. Page 10...

  • Page 11: Parts List

    Angle Plate Blade Support Shelf Rubber Foot Move Plate Screw Protective Guard Clamp Holder Magnet Guard Clamp Magnet Turn Nut for Clamp Holder Screw Locking Nut for Clamp Holder asseMBly diagraM SKU 99823 For technical questions, please call 1-800-444-3353. Page 11...

  • Page 12: Limited 90-Day Warranty

    Camarillo, CA 93011 • (800) 444-3353 not apply to you. THIS WARRANTY IS ExPRESSLY IN LIEU OF ALL OTHER WARRANTIES, ExPRESS OR IMPLIED, INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS. SKU 99823 For technical questions, please call 1-800-444-3353. Page 12...
