2-2. Periodic Inspection and
Maintenance

2-2-1. Cleaning

1. Front panel
MPE-200 is performing the air intake from the front panel
for internal air-cooling.
Therefore, the filter on the rear of the front panel can easily
accumulate the dust. Be sure to remove dust by cleaning.
If dust has accumulated in the filter, air is prevented from
flowing smoothly and this may result in a temperature rise
inside the unit. This may have an adverse effect on perfor-
mance and life of this unit.
Cleaning of the fan every month is recommended.
1. Turn off the main power of the MPE-200 and discon-
nect the AC power cord from the wall outlet.
2. Loosen the two screws (with drop-safe) and remove
the front panel in the direction of the arrow.
Screw (with
drop-safe)
Front panel
2-2 (E)
3. Remove the dust accumulated on the filter with a
2. Fan
The power supply unit of MPE-200 is air-cooled by a fan
on the rear panel.
If dust has accumulated in the intake of the fan, air is
prevented from flowing smoothly and this may result in a
temperature rise inside the power supply. This may have
an adverse effect on performance and life of this unit.
Cleaning of the fan every month is recommended.
Contact your local Sony Sales Office/Service Center for
information on cleaning the fan.
Screw (with
drop-safe)
vacuum cleaner.
n
Cleaning the filter by washing in water is recommend-
ed when there is a heavy accumulation of dust.
Be sure to dry the filter completely after it has been
washed.
Front panel
Filter
Power supply
unit
Fan
MPE-200
