Sony MPE-200 Installation Manual page 17

Multi image processor
Hide thumbs

Advertisement

2. KY-660 board
A
1
S102
2
D111
D107
D110
D109
D108
<Switch >
Ref No.
Address
S102
(A-2)
*1: Setting the RS-232C function
S102-7
S102-8
OFF
OFF
ON
OFF
OFF
ON
ON
ON
*2: The RS-232C connector of the front side is on the KY-660 board. When using it, the front panel must be removed.
(For the procedure to remove the front panel, refer to "2-2-1. Cleaning".)
MPE-200
B
CN202
RS-232C
Name
Function
_
S102-1: Bank switching of NOR flash memory
ON: Backup
OFF: Main
S102-2: Sets the starting mode.
ON: Automatically starts when the AC
power turns on.
OFF: Does not start automatically.
S102-3: Sets the starting path.
ON: Forcibly starts in the maintenance mode.
OFF: Starts with the path set on the firmware.
S102-4 to 6: Not used
S102-7, 8: Sets the RS-232C function
* * * * * 2
Front side RS-232C
Not used
Console mode
Console/System control mode
Not used
C
Side A
Factory setting
All OFF
1
2
3
4
(
indicates the knob position.)
*1
Rear side RS-232C
Console/System control mode
System control mode
Not used
Not used
5
6
7
8
1-9 (E)
