4. IPM-107 board
A
B
D1800
<LED >
Ref No.
Address
Name
D109
(E-1)
FPGA-CONFIG
D1800
(A-1)
+12 V
5. OPM-53 board
A
B
D1
<LED >
Ref No.
Address
Name
D1
(A-1)
+12 V
D112
(E-1)
FPGA-CONFIG
1-9. Installing and Setting Up the Software
For installing and setting up the software (system and application) to the MPE-200, contact your local Sony Sales Office/
Service Center.
1-12 (E)
C
D
D109
Indication color
Function
Yellow-green
Lights when FPGA configuration is complete.
Yellow-green
Displays the +12 V power supply
C
D
D112
Indication color
Function
Yellow-green
Displays the +12 V power supply
Yellow-green
Lights when FPGA configuration is complete.
E
F
1
2
Side A
E
F
1
2
Side A
Normal state
Lights on
Lights on
Normal state
Lights on
Lights on
MPE-200
