Non-cycling Refrigerated Dryer 1000-2400 SCFM
Models D1700IN, D2040IN, D2720IN, D3400IN, D4080IN
Operator's Manual
Operator's Manual
EN
Manual Del Operador
ES
FR
Manuel De L'opérateur
Manual do Operador
PT
PRINT LANGUAGE
ENGLISH
SPANISH
FRENCH
PORTUGUESE
Save These Instructions
80445521 en
Revision C
February 2012
Advertisement
Table of Contents
Related Manuals for Ingersoll-Rand D1700IN
Summary of Contents for Ingersoll-Rand D1700IN
-
Page 1: Save These Instructions
80445521 en Revision C February 2012 Non-cycling Refrigerated Dryer 1000-2400 SCFM Models D1700IN, D2040IN, D2720IN, D3400IN, D4080IN Operator’s Manual Operator’s Manual Manual Del Operador Manuel De L’opérateur Manual do Operador PRINT LANGUAGE ENGLISH SPANISH FRENCH PORTUGUESE Save These Instructions... -
Page 2: Table Of Contents
14.0 REPLaCEMENT PaRTS 7.5.6.1 MANUAL MODE AIR COOLED PARTS 7.5.6.2 AUTO RESTART MODE COMPRESSORS 7.5.6.3 REMOTE AUTOMATIC MODE MISCELLANEOUS PARTS AIR COOLED PARTS COMPRESSORS 15.0 ENgINEERINg SPECIFICaTIONS AIR COOLED CONDENSERS Non-cycling Refrigerated Dryer MODELS D1700IN, D2040IN, D2720IN, D3400IN, D4080IN ingersollrandproducts.com... -
Page 3: Introduction
Company and which Note that this is Ingersoll Rand standard warranty. Any can be passed on to the Purchaser. The Company shall not warranty in force at the time of purchase of the equipment... -
Page 4: Receiving And Inspection
Safety and Operation Precautions may result screen in place. in personal injury or equipment damage. However, Ingersoll Rand does not state as fact, nor does it Inspect unit daily to observe and correct any unsafe mean to imply, that the preceding list of Safety and operating conditions. - Page 5 • Condensate Drain Discharges Under Pressure. • Drain Requires Periodic Cleaning (Service). FAN MAY AUTOMATICALLY READ TECHNICAL MANUAL START AT ANY TIME This unit is charged with HIGH VOLTAGE refrigerant under high pressure. Non-cycling Refrigerated Dryer MODELS D1700IN, D2040IN, D2720IN, D3400IN, D4080IN ingersollrandproducts.com...
-
Page 6: Principles Of Operation
If a small amount of liquid and a large amount of air is discharged, decrease the on-time setting or increase Ingersoll Rand non-cycling dryers remove moisture, oil the off-time setting. If there is all liquid and no air vapor and other contaminants from compressed air by has been discharged, increase the on-time setting or cooling the air temperature to 36 deg.F (2.2 deg.C). - Page 7 HGBV SOLENOID (EXTERNAL CONNECTION VALVE & PIPING BY OTHERS) SOLENOID FILTER EXPANSION DISTRIBUTOR DRYER VALVE VALVE 5/8” LIQUID LINE (TYP) FAN MOTOR FAN MOTOR AIRCOOLED CONDENSER 7/8” DISCHARGE LINE (TYP) Non-cycling Refrigerated Dryer MODELS D1700IN, D2040IN, D2720IN, D3400IN, D4080IN ingersollrandproducts.com...
-
Page 8: Controls
All adjustments should be made without air flow equipped with a Microprocessor Controller. This advanced (load) on the dryer. microprocessor-based Controller has been engineered by Ingersoll Rand for use with Ingersoll Rand Compressed Air ADJUSTMENT SCREW Dryers. ADJUSTMENT SCREW LOCKING... -
Page 9: Basic User Interface
Used to accept changed parameters and set point values. • Restricted Level access for factory use only. Not used for basic dryer functions. Not to be used by customer or service technician. Non-cycling Refrigerated Dryer MODELS D1700IN, D2040IN, D2720IN, D3400IN, D4080IN ingersollrandproducts.com... -
Page 10: Display Parameters
32°F - 50°F; 1 °F Customer Set points Screen. CHLLR TEMP 34°F Temperature increments SELECT CHLLR TEMP: 36 DISPLAY Press SELECT DISPLAY as necessary to return the Microprocessor Control to the desired display parameter. Non-cycling Refrigerated Dryer MODELS D1700IN, D2040IN, D2720IN, D3400IN, D4080IN ingersollrandproducts.com... -
Page 11: Alarms And Their Functions
See Table 1 CUTOUT 7.5.6 START MODES LOW PRESSURE CUTOUT LPCO ALARM See Table 1 Ingersoll Rand dryers are capable of starting in one of HIGH TEMPERATURE HITEMP ALRM 55 °F three start modes. Note that to protect the refrigeration... -
Page 12: Installation And Initial Start-Up
A minimum of 18 inches is Ingersoll Rand dryers come factory installed with a drain required to allow free flow of air to the condenser inlet. isolation valve (D). The isolation valve permits maintenance If loads fluctuate widely, the dryer should be positioned of the automatic drain without isolating air flow to the dryer. -
Page 13: Electrical Connection
A suitable fused disconnect switch or circuit breaker, in accordance with national and local code requirements, is CAUTION recommended for all Ingersoll Rand equipment. Refer to allow 8 hours of warm-up time for the crankcase heater Section 15 for voltage requirements and load. -
Page 14: Scheduled Maintenance
Periodically, the drain should be removed and cleaned to ensure no debris from the system is trapped inside. Ingersoll Rand non-cycling dryers are equipped with a drain isolation valve, enabling the valves to be cleaned during dryer operation after the drain isolation valve has been manually closed. - Page 15 WASHER SCREW D.I.N UNIT SOLENOID APPLIANCE SOCKET SEAL WASHER PLUNGER TUBE ASSY. CABLE GLAND THREADED FLANGE GASKET PLUNGER W/ SPRING ASSEMBLY ORIFICE CUP BEVELLED WASHER STRAINER BODY SOLENOID VaLVE DETaIL Non-cycling Refrigerated Dryer MODELS D1700IN, D2040IN, D2720IN, D3400IN, D4080IN ingersollrandproducts.com...
-
Page 16: Technician Mode
Ingersoll Rand Service LOW TEMPERATURE LOWTEMP Personnel. Improperly altering the set point may result ALARM ALRM: in damage to the dryer. Contact Ingersoll Rand before LOW TEMPERATURE LOTEMP DLY: 2:00 altering the default set point. ALARM DELAY... -
Page 17: Alarm List
CHLLR TEMP: 37 “” button located above the SET button to return to the CUSTOMER MODE. Depressing the “” button again returns the controller to the default display of the CUSTOMER MODE. Non-cycling Refrigerated Dryer MODELS D1700IN, D2040IN, D2720IN, D3400IN, D4080IN ingersollrandproducts.com... -
Page 18: Troubleshooting
11.0 TROUBLESHOOTINg 11.1 INTRODUCTION Ingersoll Rand dryers are designed for reliable, trouble-free operation. In the event of any dryer malfunction, the guide below has been developed to facilitate problem identification and corrective actions. WARNING WARNING an air dryer always operates under pressure. any... - Page 19 Inspect probe and check readings thermal well against independent source (eg. temperature analyzer/pyrometer/ice bath) both in exchanger well and to ambient Problem persists Turn dryer off and consult your local distributor for further assistance Non-cycling Refrigerated Dryer MODELS D1700IN, D2040IN, D2720IN, D3400IN, D4080IN ingersollrandproducts.com...
-
Page 20: Wiring Diagram
12.0 WIRINg DIagRaM Non-cycling Refrigerated Dryer MODELS D1700IN, D2040IN, D2720IN, D3400IN, D4080IN ingersollrandproducts.com... - Page 21 12.0 WIRINg DIagRaM Non-cycling Refrigerated Dryer MODELS D1700IN, D2040IN, D2720IN, D3400IN, D4080IN ingersollrandproducts.com...
- Page 22 12.0 WIRINg DIagRaM Non-cycling Refrigerated Dryer MODELS D1700IN, D2040IN, D2720IN, D3400IN, D4080IN ingersollrandproducts.com...
- Page 23 12.0 WIRINg DIagRaM Non-cycling Refrigerated Dryer MODELS D1700IN, D2040IN, D2720IN, D3400IN, D4080IN ingersollrandproducts.com...
- Page 24 12.0 WIRINg DIagRaM Non-cycling Refrigerated Dryer MODELS D1700IN, D2040IN, D2720IN, D3400IN, D4080IN ingersollrandproducts.com...
-
Page 25: General Arrangement
13.0 gENERaL aRRaNgEMENT Non-cycling Refrigerated Dryer MODELS D1700IN, D2040IN, D2720IN, D3400IN, D4080IN ingersollrandproducts.com... - Page 26 13.0 gENERaL aRRaNgEMENT Non-cycling Refrigerated Dryer MODELS D1700IN, D2040IN, D2720IN, D3400IN, D4080IN ingersollrandproducts.com...
-
Page 27: Miscellaneous Parts
TRANSDUCER, REFRIGERANT DISCHARGE PRESSURE 0-500 PSIA 682942 TRANSDUCER, REFRIGERANT SUCTION PRESSURE 0-300 PSIA 600191 TRANSFORMER, CONTROL 0.15 KVA 684448 VALVE, HOT GAS BY-PASS (D1700IN, D2040IN ) 684590 VALVE, HOT GAS BY-PASS (D2720IN) 684273 VALVE, REFRIGERANT EXPANSION 683919 VALVE, REFRIGERANT LIQUID LINE (D1700IN) -
Page 28: Air Cooled Parts
Domestic service where interruptions in service are acceptable. Average Domestic service where some interruptions in service are acceptable. Maximum Export service or for domestic service where interruptions in service are unacceptable. Non-cycling Refrigerated Dryer MODELS D1700IN, D2040IN, D2720IN, D3400IN, D4080IN ingersollrandproducts.com... -
Page 29: Air Cooled Parts
2525 1145 26-0 11.80 25.4 17.8 NOTE: Maximum allowable operating pressure 220 psig. * D2040IN 575/3/60 has auto transformer for entire dryer, all other 575 volt models have auto transformers for fans only. Non-cycling Refrigerated Dryer MODELS D1700IN, D2040IN, D2720IN, D3400IN, D4080IN ingersollrandproducts.com... - Page 32 ingersollrandproducts.com © 2012 Ingersoll-Rand Company...
