RECOMMENDATIONS FOR THE USE,
INSTALLATION AND MAINTENANCE OF
BUILT-IN GAS CERAMIC HOBS
Dear customer,
thank you for buying one of our products.
We are sure that this new, modern, functional and practical appliance, made using the finest quality
materials, will fully satisfy your requirements. This new appliance is very easy to use, but in order to
obtain the best results, we strongly recommend that you read this booklet carefully before use.
These instructions are valid exclusively for countries the identification symbols of which appear
on the cover of the instruction booklet and the label on the appliance.
The manufacturer cannot be considered responsible for any damages to people or to things in the
event of incorrect installation or improper use of the appliance.
Toll: (800) 459-0844 P: 813-288-8890 F: 813-288-8604
MODEL: GKS 11742.0-35 F-UL
The Manufacturer cannot be held responsible for any imprecision due to printing or copying errors
contained in this booklet. The figures shown are purely indicative. We reserve the right to make any
changes to our products which we consider to be necessary or useful, also in the interest of the user,
without affecting their essential characteristics in terms of functionality and safety.
All manuals and user guides at all-guides.com
INSTRUCTIONS AND
Kuppersbusch USA
1883 Massaro Blvd. Tampa, FL 33619
COD. 04059ULKUP - 04.06.2009

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GKS 11742.0-35 F-UL and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Kuppersbusch GKS 11742.0-35 F-UL

  • Page 1 1883 Massaro Blvd. Tampa, FL 33619 Toll: (800) 459-0844 P: 813-288-8890 F: 813-288-8604 MODEL: GKS 11742.0-35 F-UL The Manufacturer cannot be held responsible for any imprecision due to printing or copying errors contained in this booklet. The figures shown are purely indicative. We reserve the right to make any changes to our products which we consider to be necessary or useful, also in the interest of the user, without affecting their essential characteristics in terms of functionality and safety.
  • Page 2 All manuals and user guides at all-guides.com DESCRIPTION OF HOBS MODEL: GKS 11742.0-35 F-UL 1 Ultra rapid gas burner of 10300 Btu/h 3 Semirapid gas burner central front 4350 Btu/h 6 Enamelled steel pan support for ultra rapid burner 7 Enamelled steel pan support 2F 8 Enamelled steel pan support wok (only on ultra rapid gas burner) 10 Burner n°...
  • Page 3: Safe Guard Instructions

    All manuals and user guides at all-guides.com SAFE GUARD INSTRUCTIONS 1) SAFE GUARD INSTRUCTIONS For all appliances: - the product shall be installed according with the a statement that the installation must conform with local codes or, in absence of local codes, with the National Fuel Gas Code, ANSI Z223.1/NFPA 54. - The product must be electrically grounded in accordance with local codes or, in the absence of local codes, with the National Electrical Code, ANSI/NFPA 70.
  • Page 4 All manuals and user guides at all-guides.com 2) BURNERS Burners Power ratings Pan Ø in cm A diagram is screen-printed above each knob on the front panel. This diagram indicates to which Ultra rapid 10300 Btu/h 24 ÷ 26 burner the knob in question corresponds. After Semirapid 4350 Btu/h 16 ÷...
  • Page 5 All manuals and user guides at all-guides.com Notes: use of a gas cooking appliance produces heat and moisture in the room in which it is installed. The room must therefore be well ventilated. Intensive and lengthy use of the appliance may require additional ventilation. This can be achieved by opening a window or by increasing the power of the mechanical exhausting system if installed.
  • Page 6 All manuals and user guides at all-guides.com CLEANING CAUTION: - Traces of liquid spilled from pans can be before cleaning the appliance, disconnect it eliminated with vinegar or lemon juice. from the gas and electricity supplies. - Never allow sugar or sugary foods to fall on the hob while cooking.
  • Page 7 All manuals and user guides at all-guides.com CLEANING - If the opening and closing of any valve is The enamelled grids, enamelled covers “A”, “B” and awkward, do not force it but request urgent “C”, and burner heads “M” (see fig. 4 and 4/A) must intervention by the technical assistance also be washed and the ignition elements “AC”...
  • Page 8: Installation

    All manuals and user guides at all-guides.com INSTALLATION TECHNICAL INFORMATION 5) FIXING THE HOT PLATE FOR THE INSTALLER The hot plate has a special seal which prevents liquid from getting into the cabinet. Strictly comply Installation, adjustments of controls and with the following instructions in order to correctly maintenance must only be carried out by a apply this seal:...
  • Page 9: Room Ventilation

    All manuals and user guides at all-guides.com INSTALLATION 6) ROOM VENTILATION The transition piece on the supply side of the regulator must be provided by the installer. To ensure correct operation of the appliance, it is important to ensure that the room where the hot Unions compatible with the hose fittings must be plate is installed has sufficient ventilation.
  • Page 10: Electrical Connection

    All manuals and user guides at all-guides.com INSTALLATION 8) ELECTRICAL CONNECTION When the appliance is connected straight to the electricity main: The electrical connections of the appliance - install an omnipolar circuit-breaker between the must be carried out in compliance with the appliance and the electricity main.
  • Page 11 All manuals and user guides at all-guides.com INSTALLATION 9) FIXING THE HOT PLATE - Fix the hob with the proper brackets “S” and turn the screw “F” until the bracket “S” stick on the top The hot plate has a special seal which prevents (fig.
  • Page 12 All manuals and user guides at all-guides.com ADJUSTMENTS Always disconnect the appliance from the - Insert a small screwdriver “D” into hole “C” (fig. 11) electricity main before making any adjustments. and turn the throttle screw to the right or left until All seals must be replaced by the technician at the burner flame has been adequately regulated to the end of any adjustments or regulations.
  • Page 13: Replacing The Injectors

    All manuals and user guides at all-guides.com CONVERSIONS 11) REPLACING THE INJECTORS paragraphs 10. The technician must reset any seals on the regulating or pre-regulating devices. The burners can be adapted to different types of The envelope with the injectors and the labels can gas by mounting injectors suited to the type of gas be included in the kit, or at disposal to the in question.
  • Page 14: Replacing Components

    All manuals and user guides at all-guides.com SERVICING Always disconnect the appliance from the Greasing the taps (see fig. 17) electricity and gas mains before proceeding If a tap becomes stiff to operate, it must be with any servicing operation. immediately greased in compliance with the following instructions: 12) REPLACING COMPONENTS...
  • Page 15 All manuals and user guides at all-guides.com TECHNICAL DATA ON THE DATA LABEL 4 BURNERS (110) PROPANE HD - 5 = 11 inches water column NATURAL GAS = 7 inches water column Σ Qn = 29300 Btu/h Natural Gas Σ Qn = 29300 Btu/h Propane HD - 5 Voltage = 120 V AC...
  • Page 16 All manuals and user guides at all-guides.com TECHNICAL ASSISTANCE AND SPARES Before leaving the factory, this appliance was tested and regulated by specially qualified experts in order to guarantee the best operating results. The original spare parts can be found only in our Technical Assistance Centres and authorised shops. Every repair or regulation operation which should become subsequently necessary must be carried out with the utmost care and attention by qualified personnel.
  • Page 17 All manuals and user guides at all-guides.com Kuppersbusch USA 1883 Massaro Blvd. Tampa, FL 33619 Toll: (800) 459-0844 P: 813-288-8890 F: 813-288-8604...
