Connect cables | 4
Connect controller to networks
1
• Connect the management port (wrench icon) on
your controller to the Ethernet switch in your man-
agement network, using a network cable.
See your network administrator for help connecting
to your switches.
• Connect 10GigE ports or GigE ports
for data connection.
Connect controller to computer
2
The serial console is needed to configure a management IP address
for the AltaVault appliance, using a client. Once this is done, further
configuration can be done using a Web browser and connecting to
the management IP address.
Note that di erent clients may have di erent connection settings.
For example, on a PuTTY connection, set the keyboard to VT100+,
flow control to OFF, and baud rate to 9600.
Connect controller to shelf
3
Altavault systems support controller to shelf cables
For optimal system performance, use one of the supported cable configurations displayed below.
• Configure up to three shelves with the AVA400 model
• Configure up to four shelves with the AVA800 model
MINI
1
Cable controller to shelf ports.
2
Cable shelf to shelf ports.
Push all cable ends in
until you hear CLICK.
AVA400/AVA800: 1 Shelf
MINI
Controller
Shelf 1
ID 00
Connect power cords
4
• Controller
Two power supplies MUST be
installed in each controller chassis.
- Ensure the power switch
on each power supply is in
the OFF position (O).
- Cable both power supplies
for each controller chassis.
DO NOT power on the controller at this point.
To host
(with mini SAS/QSFP connectors)
mini SAS HD-QSFP cable
QSFP-QSFP cable
AVA400/AVA800: 2 Shelves
Shelf 2
ID 10
MINI
MINI
Controller
Shelf 1
ID 00
• Disk shelf
X2 0 6 7
1
2
LNK
LNK
LNK
LNK
LNK
LNK
LNK
LNK
LNK
LNK
LNK
LNK
0
a
0
b
0
c
0
d
e
0a
e0b
e0c
e0d
e
0e|0e
e
0f|0f
e
0g|0g
e
0h|0h
Power switch
Use
retaining clips
To management port
1
3
5
7
9
11
13
15
1
3
5
7
9
11
13
15
1000/100/10M
LNK /
2
4
6
8
10
12
14
16
1000/100/10M
LNK /
2
4
6
8
10
12
14
16
(wrench icon) on controller
To Ethernet switch
GigE cable
To Ethernet switch 1
1
3
5
7
9
11
13
15
1
3
5
7
9
11
13
15
1000/100/10M
LNK /
2
4
6
8
10
12
14
16
1000/100/10M
LNK /
2
4
6
8
10
12
14
16
Client
and shelf to shelf cables
Latch release
faces
down
on disk shelf
SAS ports
AVA400/AVA800: 3 Shelves
Shelf 2
ID 10
MINI
Controller
Shelf 1
ID 00
Shelf 3
ID 01
Two power supplies
X3 1 4 9 A
3
MUST be installed in
4
each disk shelf.
e i 0
e j 0
e k
0
e i 0
- Ensure the power
3
switch on each power
4
supplyis in the OFF
position (O).
- Cable both power
supplies for each disk shelf.
e i 0
e j 0
e k
0
e l 0
GigE ports
10GigE ports
3
LNK
LNK
LNK
10GigE cables
4
e0a
e0b
e0c
AltaVault system
3
RJ45 serial adapter
4
LNK
0h|0h
e i 0
e j 0
e k
0
e i 0
e
Extension serial cable
to USB connection.
(QSFP/QSFP connectors).
AVA800 only: 4 Shelves
Shelf 4
ID 11
Shelf 2
ID 10
MINI
MINI
Controller
Shelf 1
ID 00
Shelf 3
ID 01
CAUTION
IOM6
PRUDENCE
LNK
LNK
1
2
3
4
IOM6
CAUTION
LNK
LNK
PRUDENCE
1
3
Power switch
For additional configurations, see
LNK
e0d
Console port
MINI
2
4
HELPFUL
LINKS.
