Tally Dascom DL-210 Maintenance Manual page 43

No. Dascom Number
63 906.904.0060
64 503.904.0130
65 501.904.0230
66 503.904.0320
67 503.904.0142
68 501.904.0200
69 503.904.0164
70 508.904.0020
71 503.904.0274
72 503.904.0420
73 503.904.0092
74 001.904.0020
75 902.904.0010
76 E.12820-100
77 906.904.0072
78 503.904.0430
79 503.904.0440
80 906.904.0041
81 503.904.0450
82 916.904.0010
83 501.904.0020
84 E.00730-060
85 503.904.0100
86 501.904.0080
87 E.40225-000
88 508.904.0090
89 E.50150-000
90 501.904.0270
91 501.904.0012
92 001.904.0091
93 508.904.0081
94 503.904.0121
95 501.904.0111
Part Name
Peeler connector
Ribbon adjustable gear
Ribbon spindle spring
Peeler cover
Ribbon Spindle
Peeler blade
Central Frame
Locating shaft, TPH
Sensor bracket
lens
Plastic guide plate
Print head cable
Cover open sensor
screw PHT（BT）M2.0*10
Black mark sensor assy.
Gap sensor frame
Gap sensor frame hook
Transmissive senor assy.
insulating strip
TPH
Stainless steel guide plate
screw PH(SW), M3.0*6
Spring locating block, TPH
Compression spring, TPH
Nut, M2.5
Square nut
Pad 5
Grounding spring
Retaining plate, TPH
Ground strap, TPH
Locking button shaft
Locking button
Locking button spring
37
QTY
1
2
2
1
2
1
1
1
1
1
1
1
1
1
1
1
2
1
1
1
1
3
2
2
2
2
1
1
1
1
1
2
2
