1.8 Platen Assembly Removal

operation
Remove the parts according to the numbering in the illustration.
1.Screw M2.6*6
Gear61 4. 4# E-ring 5. Gear 47 6. Porous Bearing
7.Finger Strip
illustration
2.Flat washer3
8.DM Earth Wire 9. Platen
26
3.Transition
