1.6 Upper Housing & Media Holder Removal
operation
illustration
(1) Open the top cover,
Rotatable plate tear bar
and then open the printer
mechanism. Hold the two
raising bosses on the
rotatable plate and then
pull outward, so as to
losse the fixing pins, and
then finally pull upward to
remove the plate.
23
