Measure S-Parameters (NA Mode)

S-parameter syntax is described by the following:
S (out | in)
out = FieldFox receiver port
in = FieldFox source port
1. Press Preset then
2. Press then Mode then
following:
S11
1-port reflection measurement.
-
S21
2-port transmission measurement.
-
S12
Reverse 2-port transmission measurement.
-
Requires the full 2-port S-parameter option.
S22
Reverse 1-port reflection measurement.
-
Requires the full 2-port S-parameter option.
OR Press Trace 6 then
Multi-trace configuration. Learn more on page 9.
3. Press Freq/Dist then either
Freq Span
and
measurement.
4. Press BW 2 then
for the measurement. Narrower bandwidths require
more time to sweep but reduces the noise.
5. Press Sweep 3 then
of data points for the measurement. More data points
requires more time to sweep.
6. Press Cal 5 to calibrate the measurement. See page
10 to learn more.
Continued on following page...
Preset
NA
then choose from the
Num of Traces
to enter a frequency range for the
IF BW
to select the IF Bandwidth
Resolution
7
then select a
Start Stop
and
to select the number
Center
or
