Further diagnostics and settings are available by cycling through the menu system.
Code
Position 12345
Remote 1/2/3/4
Right / Left Hand
Quiet Travel / Travel Alarm
Landing Stop /Pass
Powered / Manual Swivel
Edge 123
Low Batt 123
Trips 12345
Safety 123
Brake 123
Relay 123
Lost Position 123
Battery Bar (bar display
1-8)
Low battery

Mains Power, Battery Power and Power Cuts

The DC charger supplies power to a set of large internal batteries. These batteries then power the
motor which lifts the chair up and down the stairs.
If the mains power fails, you can continue to use the stairlift for a short while as the batteries store
enough power to allow you up and down the stairs a few times.

SERVICING

IF HINGE RAIL
•
•
•
•
SARY RE-APPLY LUBRICATION.
Meaning
Lifts current position on rail. Bottom end stop is 00000. Press and hold menu button to re-program.
Shows current Remote channel selection. Press adjust button to change.
Shows current installation hand selected. Press adjust button to change.
Shows current travel alarm selection. Press adjust button to change.
Shows current landing selection. Press adjust button to change.
Shows current swivel selection. Press adjust button to change.
Number of sensitive edge trips since last engineer reset. Press adjust button to reset to 0.
Number of low battery events since last engineer reset. Press adjust button to reset to 0.
Number of trips (up or down) done by control system. Not resettable.
Number of safety circuit trips since last engineer reset. Press adjust button to reset to 0.
Number of brake faults since last engineer reset. Press adjust button to reset to 0.
Number of relay faults since last engineer reset. Press adjust button to reset to 0.
Number of times position has been lost since last engineer reset. Press adjust button to reset to 0.
A bar display of battery voltage. Approx. 21V (all off) to 27V (all on).
Battery below 21V.
CHECK OPERATION OF LIMIT SWITCHES.
CHECK OPERATION OF PLASTIC GUARD COVERS.
CHECK OPERATION OF HINGE RAIL
CLEAN EXCESSIVE GREASE OF MECHANISM AND CHECK FOR DAMAGE. IF NECES-
