Setting Software Options - AmeriGlide HORIZON PLUS Installation Manual

SETTING SOFTWARE OPTIONS

IMPORTANT - If your stair lift is not properly programmed in this step,
The cover with the on/off switch can only be removed if the unit is at the top of the rail.
The Key is attached to the arm with a tie wrap. Detach it, insert into keyswitch under the armrest
and turn clockwise.
Turn lift on using the On/Off switch located on left hand side cover. Set stairlift hand, swivel
method, lift mode and display language using red buttons (as shown below) on the main Printed
Circuit Board.
Menu Button cycles through options.
NOTE: The lift must be programmed to the proper side of the stair case. It should indicate
the side as you are looking up the stair case.
NOTE: The key must be installed and turned on for the lift to function.
NOTE: There will be a 3-5 second delay before the lift will move when the arm switch is activated.
NOTE: Remote Setting 1, 2, etc. references Channel Setting, not number of remotes.
20
the remotes will not function correctly.
NOTE: If your lift is on the right side of the stair case...
Adjust Button changes settings.
