5. Orient the Handlebar (7) as shown.
Locate the Adjustment Knob (15) on the front of
the Frame (1). Loosen the Adjustment Knob and
pull it outward. Then, insert the Handlebar (7)
into the Frame.
Move the Handlebar (7) upward or downward
to the desired position, release the Adjustment
Knob (15) into an adjustment hole in the
Handlebar, and then tighten the Adjustment
Knob. Make sure that the Adjustment Knob is
firmly engaged in an adjustment hole.
6. Identify the Right Pedal (11).
Using an adjustable wrench, firmly tighten the
Right Pedal (11) clockwise into the Right Crank
Arm (49).
Firmly tighten the Left Pedal (not shown)
counterclockwise into the Left Crank Arm
(not shown). IMPORTANT: You must turn the
Left Pedal counterclockwise to attach it.
5
7
6
49
8
15
1
11
