- Page 1 INSTALLATION AND USER’S MANUAL CU - 24V - 1M Control unit comunello.com ISTRUZIONI D’USO E DI INSTALLAZIONE INSTALLATIONS-UND GEBRAUCHSANLEITUNG INSTRUCIONS D’UTILISATION ET D’INSTALLATION INSTRUCCIONES DE USO Y DE INSTALACION ИНСТРУКЦИЯ ПО МОНТАЖУ Cod. 91300174 Rev. 01 - 30.04.15...
- Page 2 LED 1 + LED 2 +LED 3 +LED 4 +LED 5 + LED 6 LED 1 + LED 2 +LED 3 +LED 4 +LED 5 + LED 6 + LED 7 Menù 3 FLASHES COMUNELLO ®Copyright 2014 - All right reserved...
- Page 3 2x2,5mm2 Flashing light 2x0,5mm2 2x1,0mm2 FG7 CEI 20-22 4A , 6A Photocell TX CEI EN 50267-2-1 2x0,5mm2 2x1,0mm2 4B , 6B Photocell RX 4x0,5mm2 4x1,0mm2 Key selector 3x0,5mm2 3x1,0mm2 Antenna RG58 max 20m COMUNELLO ®Copyright 2014 - All right reserved...
- Page 4 BATTERIA TAMPONE BACK-UP BATTERY TRASFORMATORE TRANSFORMER 230/21.7V - 7.5A LAMPEGGIANTE FLASHING LIGHT MOTORE MOTOR BLOCCO (N.C.) STOP (N.C.) 2 ND BATT ALIMENTAZIONE FOTOCELLULE PHOTOCELL POWER 2 ND STOP FINECORSA CHIUDI (N.C.) END CLOSE (N.C.) FOT+ FINECORSA APRI (N.C.) END OPEN (N.C.) PULSANTE APRI-CHIUDI (N.O.) PUSCH BUTTON (N.O.) ANTENNA...
- Page 5 RED ON M1+ BLACK ON M1- FORT like below: Led “opening direction” ON: OPENS TO THE LEFT Inner side view FORT like below: Led “opening direction” OFF: OPENS TO THE RIGHT Inner side view COMUNELLO ®Copyright 2014 - All right reserved...
- Page 6 SALIENT BLACK ON M1+ RED ON M1- SALIENT: DO NOT CHANGE the configuration! Opens to the left, closes to the right (left profile view, as in the image).
- Page 7 INSTALLATION AND USER’S MANUAL CU - 24V - 1M EC DECLARATION OF COMFORMITY: The undersigned Mr. Luca Comunello, representing the following manufacturer, Fratelli COMUNELLO Spa Via Cassola 64, 36027 Rosà (VI) – Italy DECLARES that the equipment described below: Electronic control unit...
- Page 8 Do not use the device if repairs Take all the measures required to ensure the are required. installation procedures do not affect the IP rating. COMUNELLO ®Copyright 2014 - All right reserved...
- Page 9 Adjustment can be performed in a range of between 50% and 100% of COMUNELLO ®Copyright 2014 - All right reserved...
- Page 10 The Condominium function means that during the opening movement or 1. PHOTOCELLS TEST: during the pause time the control unit will not respond to commands sent The control unit is factory set with the photocells test disabled; proceed COMUNELLO ®Copyright 2014 - All right reserved...
- Page 11 2 and then press the SEL key to select blinking LED L3 and press the SET function consists in adding, in the presence of a deceleration stage during key: LED L3 becomes steady on and programming will be completed. COMUNELLO ®Copyright 2014 - All right reserved...
- Page 12 LED L6 and then press the SET key: LED L6 becomes steady on and programming will be completed. Repeat the procedure if you wish to Fratelli Comunello SpA provides a warranty for 24 months for the correct restore the previous configuration.
- Page 13 FRATELLI COMUNELLO S.P.A. AUTOMATION GATE DIVISION Via Cassola, 64 - C.P. 79 36027 Rosà, Vicenza, Italy Tel. +39 0424 585111 Fax +39 0424 533417 info@comunello.it www.comunello.com...
