3270150/5
for DN15 to DN100 Spira-trol
Installation and Maintenance Instructions
TN203 _ E
or
TN215 _ E
IM-P361-02-EN-ISS1 CTLS
TN2000 Series
Pneumatic Piston Actuators
TN203 _ RH
PREVIOUS REFERENCE NO. IM-P327-07
Series Control Valves
TM
1. Safety information
2. General product information
3. Installation
4. Commissioning
5. Spare parts
TN215 _ SRH
IM-P361-02-EN-ISS1
CTLS
© Copyright 2018
1
Printed in France
Advertisement
Table of Contents
Related Manuals for Spirax Sarco TN203 E Series
Summary of Contents for Spirax Sarco TN203 E Series
- Page 1 PREVIOUS REFERENCE NO. IM-P327-07 3270150/5 IM-P361-02-EN-ISS1 CTLS TN2000 Series Pneumatic Piston Actuators for DN15 to DN100 Spira-trol Series Control Valves Installation and Maintenance Instructions 1. Safety information 2. General product information 3. Installation 4. Commissioning 5. Spare parts TN215 _ SRH TN203 _ RH TN203 _ E TN215 _ E...
- Page 2 IM-P361-02-EN-ISS1 CTLS...
-
Page 3: Safety Information
Spirax Sarco products are not intended to withstand external stresses that may be induced by any system to which they are fitted. It is the responsibility of the installer to consider these stresses and take adequate precautions to minimise them. -
Page 4: Protective Clothing
1.9 Tools and consumables Before starting work ensure that you have suitable tools and/or consumables available. Use only genuine Spirax Sarco replacement parts. 1.10 Protective clothing Consider whether you and/or others in the vicinity require any protective clothing to protect against the hazards of, for example, chemicals, high/low temperature, radiation, noise, falling objects, and dangers to eyes and face. -
Page 5: Returning Products
Customers and stockists are reminded that under EC Health, Safety and Environment Law, when returning products to Spirax Sarco they must provide information on any hazards and the precautions to be taken due to contamination residues or mechanical damage which may present a health, safety or environmental risk. -
Page 6: General Product Information
2. General product information 2.1 Description The TN2000 series of pneumatic piston actuators are suitable for use with DN15 to DN100 Spira-trol control valves of which three versions are available: Single-acting (with spring), Double-acting (with spring) and Double-acting (no spring). The availability of these three versions meets the requirements of valves at various differential pressures and in a variety of applications. - Page 7 11, 12 13, 14 Fig. 1 IM-P361-02-EN-ISS1 CTLS...
- Page 8 2.3 Materials (continued) Parts 15 to 41 (See page 6 for parts 1 to 14) No. Part Material Carbon steel (plated) Bearing and seal insert Carbon steel (plated) Rod seal wiper Ø20 Polyurethane DU plain bearing Ø20 PTFE/steel composite Spindle Stainless steel Connector Stainless steel...
- Page 9 TN21 only 37 TN21 only Only used with the TN2_ _ _ _ _ Only used with the TN2_ _ _ _C Only used with the TN215_ _ _ C Fig. 2 IM-P361-02-EN-ISS1 CTLS...
- Page 10 Actuator data: Acting Acting Acting Acting Actuator Travel Thrust pressure pressure pressure pressure range 0 mm 20 mm 30 mm 50 mm TN2030 and 2.5 kN 0.79 bar 1.47 bar 1.81 bar 30 mm variants 562 lbf 11.50 psi 21.31 psi 26.24 psi TN2033 and 6 kN...
-
Page 11: Installation
3. Installation Caution: Sling eyes (X, see Figure 3) are not to be used for lifting an actuated valve assembly. Sling eyes can only be used to stabilise the assembly. Suitable support of the valve and actuator will be required. See separate Installation and Maintenance Instructions for the control valve. - Page 12 3.1 Fitting the actuator (extend) to the valve Remove the screw and nut (13 and 14) then the rear and front clamp (11 and 12). Ensure the indicator scale is facing the same way as the valve name-plate. Apply the control signal pressure to the bottom of the actuator to bring the spindle (19) to the mid-travel position.
- Page 13 11, 12 13, 14 Only used Only used with the with the TN2_ _ _ _ _ TN2_ _ _ _C Fig. 5 IM-P361-02-EN-ISS1 CTLS...
- Page 14 Tighten the mounting nut to 50 N m (36.9 lbf ft). The air supply to the actuator must be 'dry and free from oil'. Contact Spirax Sarco for more details with relation to composite tube/media compatibility. For high temperature conditions, insulate the control valve and pipework only to protect the actuator.
- Page 15 Only used Only used with the with the TN2_ _ _ _ _ TN2_ _ _ _C Fig. 6 IM-P361-02-EN-ISS1 CTLS...
-
Page 16: Removing The Actuator From The Valve
4. Commissioning Note: Before actioning any maintenance programme observe the 'Safety information' in Section 1. Warnings: 1. Actuator support will be required due to weight. 2. The actuator contains a pre-compressed spring. 3. Special assembly tool required. 4. Use POLYLUB GLY 801 (lubricating grease) only. The TN2000 series of pneumatic actuators are maintenance free. - Page 17 11, 12 13, 14 Only used Only used with the with the TN2_ _ _ _ _ TN2_ _ _ _C Fig. 7 IM-P361-02-EN-ISS1 CTLS...
- Page 18 4.2 Replacing the 'O' and 'X' rings (SE and DE actuators) Note: Remove the actuator from the valve as described in Section 4.1. Note: Depending on the actuator size there is either 3 or 4 short threaded bars which must be removed last to ensure that the spring tension is removed before taking the actuator apart.
- Page 19 4.3 Replacing the 'O' and 'X' rings (SR and DR actuators) Note: Remove the actuator from the valve as described in Section 4.1 Note: There are 5 long securing nuts that must be removed last to ensure that the spring tension is removed. Loosen and remove the connector (20), see Figure 9.
- Page 20 4.4 TN203_SEH or TN203_SRH (handwheel) Note: Ensure the handwheel has no comprehessive load on the actuator springs. Remove the plastic barrel plug (A), hold the actuator spindle at point (B) with a spanner and simultaneously loosen and remove the screw (C). Remove the handwheel (D), taking care not to displace the internal bearing (F).
- Page 21 4.5 TN215_SEH or SRH (handwheel) Note: Ensure the handwheel has no comprehensive load on the actuator springs. Rotating the handwheel clockwise retracts the spindle, rotating it anti-clockwise extends the spindle. The actuator is shown in the fully extended position) Remove the plastic cap (A), hold the actuator spindle at point (B) with a spanner and loosen the screwed insert (C), or screw (for...
-
Page 22: Spare Parts
Always order spares by using the description given in the column headed 'Available spares' and state the actuator model. Example: 1 - 'O' ring kit for a Spirax Sarco TN2033SEB pneumatic piston actuator. Fig. 14 TN203 _ SEH Fig. 15 TN203 _ SRH... - Page 23 Fig. 16 TN215 _ ECH Fig. 17 TN215 _ RBH IM-P361-02-EN-ISS1 CTLS...
- Page 24 IM-P361-02-EN-ISS1 CTLS...
