Hardware
Specifications
Dimensions
Weight
Enclosure
Pump Head / Motor Options
Pressure Sensors
Pressure Displayed
Pressure Range: 0-60 psi
(0 - 4.14 bar)
Electrical
Software


8
Thick-walled (0.090¨) pump tubing: #15, 24 and #35. Flow Range: 59 to
Thin-walled (0.060¨) pump tubing: #13, 14, 16, 25, 17, and #18. Flow Range: 0.5 to
554 mL / min. Recommended for small aliquots at reasonable speeds.
Thin walled (0.060¨) pump tubing: #13, 14, 16, 25, 17 and #18.Flow Range: 0.03 to
24.3 mL / min. Recommended for very small aliquots where speed is not an issue.
Accommodates one SciPres
P2 and P3 Ports may be used as alternates. Pressure is used for monitoring
and alarms. The user selects P1, P2 or P3 as the pressure source.
The default pressure range of the sensors is 0-60 psi (0 - 4.14 bar), and is
calibrated at the factory. Most peristaltic pumps generate pressures up to
40 psi (0 - 2.76 bar). This can be re-calibrated using an external pressure
100-240 V , 47-63 Hz, 150 VA, listed Class 2 switching power supply.
Power
Battery
CR1220, used to support the internal clock only, not user serviceable.
Choice of four motors: 8, 160, 600 and 3400 RPM at 24V, 3.8 Amperes,
Motor
Variable Pump Speed optically encoded servo-controlled motors.
Encoder
Weight Ratio
Auto-weighing and dilution of samples with pressure monitoring.
Mode
Volume
Programmable batch dispensing by volume with pressure monitoring
Dispense Mode
Weight
Programmable batch dispensing by weight with pressure monitoring
Dispense Mode
Setup Mode
Manual Mode
W: 5.75¨ (14.6 cm); Height 8.5¨ (21.2 cm); D: 11¨ (27.9 cm)
14 lb (6.4 Kg)
Aluminium / Steel; Corrosion Resistant, Recessed Handle.
1. Tandem™ 1082 peristaltic pump head with 600-RPM motor
2258 mL / min. Recommended for most applications.
2. Tandem™ 1081 peristaltic pump head with 160-RPM motor
3. Tandem™ 1081 peristaltic pump head with 8-RPM motor
4. Piston and Magnetic Gear Heads
Also available as your application requires.
®
pressure sensor using the P1 Port.
With a resolution of 0.1 psi (0.007 bar); choice of psi, bar, kpa.
reference source.
Double fused: 1A-T, 250V (CE: IR35A 250V ).
Not all heads can accommodate all motors.
100 lines per / rev. for 600-RPM motor.
120 lines per / rev. for all other motors.
Selection of user preferences and interface options
Manual pump control with pressure monitoring, no alarms.
