Parker SciLog LabTec Installation, Operating, & Maintenance Instructions page 54

5.11 Mettler Toledo ICS425 Scale Parameters
To enter the Setup mode, press and hold the "Transfer" key until the word CODE appears on the
display. Then press "Zero", "Zero", "Zero", "Transfer", and an interactive menu screen is
presented. Use the displayed arrows and the related buttons to navigate the menu and confirm
the following settings are enabled.
Level 1
SCALE
Comm
When exiting the Menu a prompt to save occurs, press OK to save the changes.
Note: The bold parameters listed are the only custom settings needed for communication with
Parker systems. All others should remain at factory defaults. Consult your scale manual for help
navigating through the scale menu. If stability is an issue, adjust the Vibration and Stability
settings as needed.
Setup Mode, select "METLER", see SETUP: SCALE: MANUF. By making this selection, the system will
implement the correct parameters for communicating with this scale.
You will also need P/N 080-072ICS Cable, Mettler Balance, ICS M-12.
Scales purchased with the system through Parker will be configured and tested to- gether with the
LabTec™ as a system at the factory.
54
Level 3
Disp Unit & Res
Zero Filter
COM1
Level 3 Selected Menu Item
Disp Unit 1
Disp Unit 1
Disp Resolution OFF (sets to default value)
AZM
Vibration
Process
Stability
Mode
Param RS 232
g
g
OFF
Medium
Dosing
Standard
Dialog
Baud 9600
Parity 8 None
H. Shake OFF
