Software / Program Setup:
1. For weight ratio applications such as this one, the only thing that must be setup prior to editing
and running the program is the scale (or scale) that is in use. If purchased from Parker, this has
already been done. If purchased separately, obtain the needed settings from Parker Technical
Support.
2. On the front panel of the LabTec™, press the "Exit" key until you reach the main or
"Mode Select" menu.
3. Press the "Up" or "Down" key until you reach the "Setup" mode.
4. Press "C" to select the Setup mode, and "A" as needed to move up to "Scale". Then press "C"
to select "Scale" and again to select "Scale Manuf".
5. Use "A" or "B" to move up or down thru the list, and when "METLER" is shown, press "C"
to select it. Then press the "Exit" key until you return again to the main or "Mode Select" menu
and you are ready to proceed to editing and running a program.
12
Mode Select SETUP
Up Down
A B
-SELECT- SCALE MANUF.
Up Down
A B
SCALE MANUF: METLER
Up Down
A B
Select
C
Select
C
Select
C
