Quick Start: "Dispensing by Volume"
Equipment: You will need the following items to get started:
Parker Part N°.
N/A
200-LABT-1682
400-124
400-491A
N/A
Hardware Setup:
1. Unpack all the components, visually identify and inspect for damage.
2. At the dispensing station, place the solution reservoir to the far left, and the LabTec™ to its
right. Position the
dispensing tip over the appropriately sized container.
3. Plug in and power up the LabTec™.
4. Cut approximately 10 feet of the #24 tubing and install the dispensing tip or filter on one end.
Mount that end of the tubing in the tubing clamp and position it so that it is just above
the container.
5. Route the tubing to the LabTec™, open the head by rotating the lever 180 degrees counter
clockwise, and place the tubing over the upper set of rollers. Confirm that the tubing is under
the centering springs and close the head by rotating the lever back to its original position.
6. Route the remaining tubing to the solution reservoir and attach it as appropriate.
Note: If you purchased the LabTec™ with your aliquot sizes preprogrammed by Parker the
calibrations have been done for you. If this is not the case, or you have performed a Factory
Reset, you will need to edit the individual aliquots (Edit 1-10) as shown below.
16
Description
Any Container or Solution
Reservoir
LabTec™ CP-200 w/1082 Head
Silicone #24 Tubing
Dispensing Tips
Container to be filled
Quantity
1 pc
1pc
25ft (1 pkg)
1pkg
1pc
