I N S T A L L A T I O N I N S T R U C T I O N S
Instrucciones de instalación
Installationsanleitung
Instruções de Instalação
Carts and Stands Horizontal Array Accessory
Istruzioni di installazione
Installatie-instructies
Instructions d´installation
KFA-220/225
KFA-320/325
Portuguese Product Description
Spanish Product Description
German Product Description
Italian Product Description
Dutch Product Description
French Product Description
KFA SERIES
Advertisement
Related Manuals for CHIEF KFA Series
Summary of Contents for CHIEF KFA Series
- Page 1 Instrucciones de instalación Istruzioni di installazione Installationsanleitung Installatie-instructies Instruções de Instalação Instructions d´installation KFA-220/225 KFA-320/325 Carts and Stands Horizontal Array Accessory Spanish Product Description German Product Description Portuguese Product Description Italian Product Description Dutch Product Description French Product Description KFA SERIES...
-
Page 2: Installation Instructions
If your display uses a longer screw size than those included in the kit, DO NOT use the screws Chief® and Centris™ a registered trademarks of Milestone AV provided with the kit. Use the screws provided with your Technologies. - Page 3 Installation Instructions KFA SERIES KFA-220 DIMENSIONS CLAMP FOR ATTACHING TO PF AND MF SERIES 13.68 CARTS AND STANDS 5.68 23.83 IF SAME SIZE DISPLAY IS USED FOR BOTH, MAXIMUM SCREEN WIDTH OF 22.7". 1.96 4.50 KFA-225 DIMENSIONS CLAMP FOR ATTACHING TO PF AND MF SERIES 17.24...
- Page 4 KFA SERIES Installation Instructions KFA-320 DIMENSIONS CLAMP FOR ATTACHING TO PF AND MF SERIES 20.80 CARTS AND STANDS 528.3 7.93 201.5 37.14 943.3 IF SAME SIZE DISPLAY IS USED FOR ALL THREE, MAXIMUM SCREEN WIDTH OF 18.0". 1.96 49.8 4.50 114.3...
- Page 5 Installation Instructions KFA SERIES LEGEND Tighten Fastener Pencil Mark Apretar elemento de fijación Marcar con lápiz Befestigungsteil festziehen Stiftmarkierung Apertar fixador Marcar com lápis Serrare il fissaggio Segno a matita Bevestiging vastdraaien Potloodmerkteken Serrez les fixations Marquage au crayon Loosen Fastener Drill Hole Aflojar elemento de fijación...
-
Page 6: Tools Required For Installation
KFA SERIES Installation Instructions TOOLS REQUIRED FOR INSTALLATION 5/32" (included) PARTS (refer to Table 1 for quantities and part descriptions) -
Page 7: Display Installation
If removing existing head assembly from cart/stand, do so prior to installing KFA Series arrays. Table 1: Parts IMPORTANT ! : The KFA Series arrays can be used in addition to the existing head assembly as long as the ITEM... - Page 8 KFA SERIES Installation Instructions Attach Centris Head to Recessed Mount Display (C) x 2 CAUTION: If display uses a screw size other than those included in the kit, DO NOT use the screws provided. Using the wrong screws could result in damage to your monitor.
- Page 9 Installation Instructions KFA SERIES Array Rail (G or D) x 4 End Lock Centris Head (E or F) x 4 Centris Head End Lock Retaining Screw Figure 10 Display Display Adjustment These pivot arrays allow horizontal, pitch, roll, and yaw...
- Page 10 KFA SERIES Installation Instructions right until properly positioned. 3. Tighten Centris bracket front adjustment knob. pitch/roll adjustment knob Figure 12...
- Page 11 Installation Instructions KFA SERIES...
- Page 12 Europe A Fellenoord 130 5611 ZB EINDHOVEN, The Netherlands P +31 (0)40 2668620 F +31 (0)40 2668615 Chief Manufacturing, a products division Asia Pacific A Office No. 1 on 12/F, Shatin Galleria of Milestone AV Technologies 18-24 Shan Mei Street...
