- Page 1 I N S T A L L A T I O N I N S T R U C T I O N S Instrucciones de instalación Istruzioni di installazione Installationsanleitung Installatie-instructies Instruções de Instalação Instructions d´installation K1 Single Column with iPad®2/iPad®3 Mount Spanish Product Description German Product Description Portuguese Product Description Italian Product Description Dutch Product Description French Product Description...
-
Page 2: Installation Instructions
K1C1I2B up to (and the information contained in this document. including) the display does not exceed 25 lbs (11.34 kg). Chief® is a registered trademark of Milestone AV Technologies. All rights reserved. WARNING: Use this mounting system only for its intended use as described in these instructions. - Page 3 Installation Instructions K1C1I2B LEGEND Tighten Fastener Pencil Mark Apretar elemento de fijación Marcar con lápiz Befestigungsteil festziehen Stiftmarkierung Apertar fixador Marcar com lápis Serrare il fissaggio Segno a matita Bevestiging vastdraaien Potloodmerkteken Serrez les fixations Marquage au crayon Loosen Fastener Drill Hole Aflojar elemento de fijación Perforar...
-
Page 4: Tools Required For Installation
K1C1I2B Installation Instructions TOOLS REQUIRED FOR INSTALLATION 1/8" (included) 3/16" (included) PARTS A (1) [arm assembly] C (4) D (4) M4x12mm G (4) H (4) F (4) M4x12mm M4x20mm B (1) M4x12mm [adapter plate] E (1) [iPad interface] J (1) K (1) 3/16"... -
Page 5: Low Profile Installation
Installation Instructions K1C1I2B Assembly And Installation Low Profile Installation Remove top cap from column. (See Figure 3) Connecting Arm Assembly to Desk Slide mount assembly off of column. (See Figure 3) Standard Installation Loosen clamp screw until enough space is created between clamp and mount to allow for desk mounting.(See Figure 1) NOTE: If space is limited behind desk (i.e. - Page 6 K1C1I2B Installation Instructions iPad2®/iPad3® Installation Use four M4x12 Phillips flat head screws (C) to connect iPad® interface (E) to adapter plate (B). (See Figure 7) Remove quick release faceplate from arm assembly (A) by pressing quick release tab and sliding faceplate off mount. (See Figure 5) quick release tab (C) x 4...
- Page 7 Installation Instructions K1C1I2B To release the iPad® from the mount, firmly hold the iPad® Adjustments while pressing back on the tab to release and remove the Column Height Adjustment iPad®. (See Figure 9) Loosen column adjustment knob. (See Figure 11) Adjust height to desired level.
-
Page 8: Cable Management
K1C1I2B Installation Instructions Head Tilt Adjustment Portrait Adjustment Adjust head tilt to desired tilt position. (See Figure 13) The iPad® may be adjusted 90 degrees in either direction in order to provide a portrait view of the iPad®. Adjust head tilt tension screw to change the adjustment tension. - Page 9 Installation Instructions K1C1I2B...
- Page 10 K1C1I2B Installation Instructions...
- Page 11 Installation Instructions K1C1I2B...
- Page 12 Europe A Franklinstraat 14, 6003 DK Weert, Netherlands P +31 (0) 495 580 852 F +31 (0) 495 580 845 Chief Manufacturing, a products division Asia Pacific A Office No. 1 on 12/F, Shatin Galleria of Milestone AV Technologies 18-24 Shan Mei Street...
