INSTALLATION GUIDE
Ramus Single Lever Vessel Faucet
FVS-1007
www.kraususa.com I Toll Free: 1.800.775.0703 I © 2017 Kraus USA Inc. I REV. August 16, 2018

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FVS-1007 and is the answer not in the manual?

Questions and answers

Summary of Contents for Kraus FVS-1007

  • Page 1 INSTALLATION GUIDE Ramus Single Lever Vessel Faucet FVS-1007 www.kraususa.com I Toll Free: 1.800.775.0703 I © 2017 Kraus USA Inc. I REV. August 16, 2018...
  • Page 2 Congratulations on the purchase of your new Kraus plumbing fixture! Please keep the box and packaging materials until your product is completely installed. If you have any questions, require technical assistance, or have any problems with your product: DO NOT RETURN TO STORE Please contact our Customer Service Team 1-800-775-0703 / customerservice@kraususa.com...
  • Page 3: Prior To Installation

    Make sure you have all necessary parts by checking the diagram and parts list. If (257mm) (21mm) 1 15/16” ∅ 1 15/16” any part is missing or damaged, please contact Kraus Customer Service at 800- ∅ 50mm) ∅ 50mm) 1 15/16”...
  • Page 4: Before Installation

    BEFORE INSTALLATION Check to make sure you have the following parts: Included Parts: • Faucet • Rubber Washer • Metal Washer • Mounting Nut • Mounting Screws • Base Trim Ring • Rubber Washer • Hot & Cold Waterlines...
  • Page 5 Faucet Installation Procedure 5 4/5” (147.3mm) 6 7/8” (175.4mm) 3 3/4” 3/8” (96mm) (10mm) 5 4/5” (147.3mm) 6 7/8” (175.4mm) 3 3/4” 3/8” (96mm) (10mm) 7/8” (22mm) 19.7 º 10 1/8” 8 5/16” 12 7/16” 7/8” (257mm) (21mm) (316mm) (22mm) 19.7 º...
  • Page 6 1 15/16” ∅ 50mm) ∅ Step 1 1 3/4” ∅ 45mm) ∅ Remove rubber washer (8A), metal washer (8B), mounting 1 15/16” ∅ nut (8C), and mounting 50mm) ∅ screws (8D). Keep the base 1 5/8” trim ring (7A) and rubber (42.5 mm Max) washer (7B) on the base of the faucet...
  • Page 7 Step 3 Install flex water supply lines on the angle stops and tighten with an adjustable wrench. Turn on both the cold and hot main valves Apply pipe tape (optional) Step 4 After installing the faucet, remove the aerator (6) with the included aerator key (10).
  • Page 8 Replacement Parts Keep this manual for ordering replacement parts. 1. (A) Index Button (B) Set Screw 2. Metal Handle 3. Trim Cap 4. Locking Nut 5. Ceramic Disc Cartridge 6. Aerator 7. Mounting Hardware (A) Base Trim Ring (B) Rubber Washer 8.
  • Page 9: Troubleshooting

    Trouble - Shooting If you have followed the instructions carefully and your faucet still does not work properly, take the following corrective steps: P R O B L E M C A U S E A C T I O N Leakage under the Adjusting locking nut Remove handle index...
  • Page 10 (1) year. The warranty commences from the initial date of purchase by the owner or trade professional, from an authorized Kraus dealer, through the one (1) year term of the original owner or end-user.
  • Page 11 Rico shipping charges may apply). International shipping fees are not included. COMMERCIAL WARRANTY Kraus extends the above warranty for a period of one (1) year to purchasers of products for industrial, commercial, and business use. All incidental or consequential damages are specifically excluded. No additional warranties, express or implied, are given, including but not limited to any implied warranty of merchantability or fitness for a particular purpose.
  • Page 12 IMPORTANT Register Your Kraus Product Activate Your Warranty Access Premium Customer Support Get Product Information REGISTER TODAY http://www.kraususa.com/registration www.kraususa.com...
