- Page 1 FS-70 AMPLIFIER WITH SIREN N Instruction manual...
- Page 2 We take this opportunity to thank you for buying this product. We recommend you read the instruction manual before switching on the machine and follow the instructions that are given. Keep the manual for future reference. SECURITY AND THE ENVIRONMENT ELECTRICAL SECURITY Check that the current in the mains connection where the machine is to be installed corresponds to the power supply of the machine.
-
Page 3: Exemption Of Liability
The characteristics of the equipment and the content of the manual can change without forewarning. FONESTAR, S.A. does not assume responsibilities regarding the inappropriate use of the equipment or the information supplied in this instruction manual, and specifically disclaims any implied liability for marketability or fitness for any other use. -
Page 4: Controls And Functions Front Panel
DESCRIPTION - Amplifier with siren. - Priority paging. - Assembly in vehicles. CONTROLS AND FUNCTIONS FRONT PANEL 1.- SIREN 1-2: siren selector. To activate the selected siren. Two types of siren can be selected: high-low tone or long-short tone. 2.- MIC: unbalanced microphone input, 6.3 mm mono jack connector. 3.- AUX: unbalanced AUX line level input, 6.3 mm stereo jack connector. -
Page 5: Speaker Connection
CONNECTION Connect the cables supplied in to the screw terminals on the back panel of the amplifier. SPEAKER CONNECTION Connect the output terminals to the speaker or speakers. The brown cable (+) to the positive terminal and the white cable (-) to the negative terminal. Make sure that the connections have been made correctly and that they have been well insulated to avoid short-circuits in the speaker output. -
Page 6: Installation
INSTALLATION Install the amplifier with the assembly brackets supplied. INSTRUCTIONS FOR USE Before switching the amplifier on or off, move the volume controls to their minimum. Make the connections with the amplifier switched off. Switch the amplifier on. Adjust the volume while there is a signal in the input that is being adjusted. MICROPHONE INPUT PRIORITY OVER AUXILIARY INPUT The amplifier is supplied with the priority function deactivated. -
Page 7: Specifications
SPECIFICATIONS FS-70 CHARACTERISTICS P.A. amplifier. Siren. Priority paging. Vehicle assembly. POWER 60 W máximo, 40 W RMS RESPONSE 80-12 000 Hz DISTORTION Harmonic: < 3% at 1 kHz 1 unbalanced mic., 6.3 mm jack 10,000 Ω 4 mV INPUTS 1 stereo auxiliary, 6.3 mm jack and 2 x RCA 10,000 Ω 100 mV CONTROLS Volume: Mic. -
Page 8: Declaration Of Conformity
This product has been tested and has passed the corresponding quality control prior to being put on the market. FONESTAR guarantees the suitability of the product for its specified use during a period of 2 years from the delivery date and commits itself to repair or substitute the goods as expressed in the Spanish law ‘La Ley General para la Defensa de los...
