FIRST INSTALLATION

b
The child seat consists of a booster seat (d) and a backrest (a) with height
a
adjustable shoulder and headrest. Only the combination of both parts provides best
protection and comfort to your child.
c Warning! The parts of the CYBEX Solution X2-fix must not be used alone or in
combination with boosters, backrests or headrests from other manufacturers
a
or of a different product series. In such cases, the certification expires
immediately.
d
d
Connect the backrest (a) to the booster (d) by hooking the guide lug (b) on the axis
(c) of the booster (d).
Note! Please keep the instruction manual close by for future reference (e.g. by
storing it under the elastic cover at the rear side of the backrest.)
Warning! Please make sure that the plastic parts of the child seat never get
jammed (e.g. in the car door or by adjusting the back seat).
Insert the Linear Side-impact Protection (L.S.P. System) pads on both sides into the
mounting holes (z), then push down until they click into place.
z

ADJUSTMENT REGARDING THE CHILD'S HEIGHT

e
e
A headrest can only provide the best protection and comfort for your child if optimally
adjusted. Only then it can guarantee the optimal position of the diagonal belt (f). You
can adjust the height of the Solution X2-fix headrest (e) in 11 positions. The shoulder
f
rest is attached to the headrest and does not have to be adjusted separately. You
h
can check the optimal adjustment of the headrest by trying to fit exactly two fingers
between the headrest and the shoulders of the child.

ADJUSTMENT OF THE HEADREST

• Place your child in the child seat.
• Pull the adjustment handle (h) in order to unlock the shoulder and headrest.
• Bring the shoulder and headrest (e) in the desired position.
• As soon as you let go of the adjustment handle (h), the shoulder and headrest (e)
locks automatically.
