- Page 1 HT500 SET USER MANUAL generallife.com.tr...
- Page 2 generallife.com.tr...
-
Page 3: Table Of Contents
HT500 SET RECEIVER HT500 SET RECEIVER PLACEMENT HT500 SET RECEIVER SETUP HT500 SET SMART ROOM THERMOSTAT HT500 SET SMART ROOM THERMOSTAT PLACEMENT HT500 SET SMART ROOM THERMOSTAT SETUP MOBILE APP - MODES LED LIGHT COLOR EXPLANATIONS- RECEIVER DECLARATION OF CONFORMITY... -
Page 4: About General Life
ABOUT GENERAL Life ISIPARK İÇ VE DIŞ TİCARET A.Ş. created GENERAL LIFE brand, which is one of the leading brand in its sector. Established and growing with 100% domestic capital, GENERAL Life presents its products to users in many countries of the world with its exports and represents Turkey in the World. -
Page 5: What Is Smart Room Thermostat
HT500 SET can placed to anywhere else in your home owing to working option with ... -
Page 6: Rules To Be Considered For Safety
In case of damages and malfunctions because of external use (contact with liquid, fall into place, etc.) , ask for help from services. 11- Contact our service for maintenance and repair of the HT500 SET and its appliances. Maintenance and repair of the product and equipments should be performed by ISIPARK İÇ... -
Page 7: Ht500 Set And Equipments
1- HT500 SET AND EQUIPMENTS THERMOSTAT EQUIPMENTS HT500 SET Holder Adapter USB Cable Battery Room Thermostat (Alkaline) RECEIVER EQUIPMENTS HT500 SET Receiver Power Cable Pegs And Screws... -
Page 8: Technical Data
2-TECHNICAL DATA Room Thermostat Technical Data 5V (DC) Feeding Voltage (Usage with Adapter) 3V DC (2 x AAA alkaline battery) Feeding Voltage (Usage with Battery) 500 mA Maksimum Load Current (Usage with Adapter) 80 mA Maksimum Load Current (Usage with Battery) 131mm / 74mm / 25.5mm Dimensions 0.1 C... -
Page 9: Ht500 Set Receiver
3- HT500 SET RECEIVER 1-Receiver LED Light 2-Sync Button: Syncs receiver and room thermostat. 3-Manual Button: Deactivates receiver and allows you to use boiler manually. 4-Receiver Power Cable Input 5-Boiler Connection Cable Input... -
Page 10: Ht500 Set Receiver Placement
4- HT500 SET RECEIVER PLACEMENT The important thing to note in the HT500 SET receiver placement is that avoiding physical contact with boiler and protecting against materials such as liquid, dust etc. You can place your receiver in boiler's cabinet without physical contact with boiler or mount receiver to wall by using Receiver Wall Mount Schematic which in page 20. -
Page 11: Ht500 Set Receiver Setup
Primarily, shut down electrical current which your boiler is connected (fuse, power outlet etc.) Connect one of the boiler connection cable to HT500 SET receiver as shown in the Connection Scheme. Connect other boiler connection cable end to boiler's room thermostat input as ... -
Page 12: Ht500 Set Smart Room Thermostat
6- HT500 SET SMART ROOM THERMOSTAT Battery Indicator Outdoor Temperature Internet Connection Indicator Setted Temperature Key Lock Room Temperature Boiler is Working Outside Mode Sleep Mode Program Mode Home Mode Manual Mode Location Mode Mode Button Temperature Set Button Temperature Set Button... -
Page 13: Ht500 Set Smart Room Thermostat Placement
Avoid installing the HT500 SET where there is a lot of air circulation such as door entry or window edges. Also, do not place in places near heat units (central heating system, fireplace, etc.) and places that receive direct sunlight. -
Page 14: Ht500 Set Smart Room Thermostat Setup
Warning: Please throw away dead batteries to trashes special only for batteries. 8- HT500 SET SMART ROOM THERMOSTAT SETUP 1- Power on the device by using adapter which you received with HT500 SET. “1” number will be seen on display. It means, HT500 SET is ready for smart setup. - Page 15 2- Scan QR Code below via your smartphone. You can install HT500 SET mobile application from Apple Store or Google Play to your smartphone with that code. (You may need QR Code Reader App regarding to your phone's model and brand) 3- Complete your membership by enter into the mobile application which you downloaded.
-
Page 16: Mobile App - Modes
9- MOBILE APP – MODES With HT500 SET' s Home-Sleep-Outside-Program-Location and Manual mods, you can warm up as you want and you can save money. Home Mode will fix temperature on set value. Recommended to use when you are at home. Suggested temperature value is 23 C. -
Page 17: Led Light Color Explanations- Receiver
10- RECEIVER LED LIGHT COLOR EXPLANATIONS Green Modem synced with thermostat and Works properly. Green Flashing Pressed to receiver sync button and waiting for thermostat sync signal. Receiver has energy but no thermostat synced. Red Flashing Boiler shut down because no signal from thermostat more than 22 minute. -
Page 18: Declaration Of Conformity
Brand : GENERAL Life Product Name : HT500 SET Product Type : Smart Room Thermostat The product manufactured by ISIPARK and mentioned above is connected wirelessly at 2.4 Ghz internet and periodically shares the temperature and status information with the server on the internet. -
Page 19: Warranty Conditions
WARRANTY CONDITIONS 1- Warranty starts at the delivery date of devices and equpments and warranted against manufacturing defect for 2 years. 2- Devices and equipments are delivered to customers in operation. Mounting and other connections will be additional fee for service. 3- Devices will maintenance and repair in our factory and should send by contracted transportation company. - Page 20 rusting, oxidation is out of warranty. 13- The transport damage is out of warranty. Customers can take a transportation insurance. 14- Damages by virtue of grid voltage are out of warranty. 15- Damages because of force majeure like flood, earthquake, fire etc. are out of warranty. 16- All parts of the product are under warranty of our company.
-
Page 21: Warranty Certificate
MODEM WALL HANGER SCHEME 64 mm... - Page 22 ISIPARK reserves the right to change and develop product specications and user manual. *For all the changes, you can visit generallife.com.tr...
