4- HT500 SET RECEIVER PLACEMENT

The important thing to note in the HT500 SET receiver placement is that avoiding
physical contact with boiler and protecting against materials such as liquid, dust etc.
You can place your receiver in boiler's cabinet without physical contact with boiler or
mount receiver to wall by using Receiver Wall Mount Schematic which in page 20.
CONNECTION SCHEME
COM NO
