Page 1: User Manual
User Manual 1/3" HD Dome, Fixed, Day&Night, 1920x1080, Infrared, 1,34mm, 360°, Indoor, 12VDC TSD-52F0013P0A... -
Page 2: Table Of Contents
Table of Contents General safety instructions ....................3 1. Product Features ......................5 2. The Overview ........................ 6 3. Installation ........................7 3.1 Connections ..........................7 3.2 Separate the main body of the camera and the base ..............7 4. Menu Operation ......................8 4.1 Main Menu .......................... -
Page 3: General Safety Instructions
General safety instructions Before switching on and operating the system, first read this safety advice and the operating instructions. Keep the operating instructions in a safe place for later use. Installation, commissioning and maintenance of the system may only be carried out by authorised individuals and in accordance with the installation instructions - ensuring that all applicable standards and guidelines are followed. - Page 4 It is unavoidable that during manufacture and to a certain extent during later use, humidity will be present in the ambient air within the device's housing. In the event of large temperature fluctuations, this humidity may condense inside the housing. To avoid this condensation inside the very tightly sealed housing, the manufacturer has inserted silica gel bags in the housing.
-
Page 5: Product Features
1. Product Features Full HD Image Quality and Details: A high-resolution megapixel sensor provides latency-free 1920x1080P Full HD resolution video to ensure that you won’t miss a thing. Day/Night Surveillance: Integrated infrared LED illuminates darkness and provides a clear picture at night for a dependable, 24-hour surveillance solution. -
Page 6: The Overview
2. The Overview 1. Camera Lens. 2. Light Sensor: Detects light levels and adjusts IR-LEDs accordingly. 3. Micro SD Card Slot: Insert a micro SD card for firmware upgrading. 4. Power LED. -
Page 7: Installation
3. Installation Please follow the instructions below to set up the system. 3.1 Connections 1. Connect the video output (①) from the camera to the DVR via BNC connector. 2. Connect the inlet (②) to an external power supply. Please connect with the 12V DC Power Supply. 3. -
Page 8: Menu Operation
4. Menu Operation This section shows you how to operate and manage the camera. The operation interface of the different DVR may differ. Please refer to the actual operation interface. The OSD Menu Structure: WALL 1O / 1P VIEW TYPE 1P / 2P / 1O3R / 1O1R1P CEILING / 2R1P... -
Page 9: Main Menu
4.1 Main Menu There are 2 ways to enter the camera’s OSD menu: By the In-line Joystick of the Camera: 1. The OSD menu will be displayed by pressing the joystick of the camera. 2. Press right direction to enter the OSD menu. Navigate through the menus and change parameters using the joystick via pressing the direction buttons. -
Page 10: Video Type
4.2 Video Type The video types are adjustable from both Wall and Ceiling mounting positions. Menu 1. Mounting type Ceiling Viewing mode View Window Auto Pan Rotate → 2. Video Setting → 3. System → Exit 1. Viewing mode: Select the multiple viewing modes as you need. 1O: One original fisheye view. -
Page 11: Video Setting
4.3 Video Setting Configure the details of the video settings setup for your camera. Video Setting Menu 1. Mounting type Ceiling 1. Day/ Night Night Mode Viewing mode 2. Mirror 3. D-WDR View Window → 4. Advance Auto Pan Rotate →... - Page 12 Sharpness: Set the value to automatically adjust the sharpness of the image to get a clear image. The greater the value is, the stronger the effect will be. Saturation: Saturation indicates the brightness of the color. The higher the saturation, the brighter the color is.
-
Page 13: System
4.4 System Displays all the information about your device. Menu SYSTEM 1. Mounting type Ceiling 1. Firmware Version V1.04 Viewing mode → Update 2. Language English View Window Auto Pan 3. Video Format NTSC Rotate → 2. Video Setting → 4. - Page 14 camera next to test its operation. If the camera remains working normally, please go back to step 3; otherwise, please inform your technical support. Make sure that the SD card is inserted in a correct position in step 2, or the camera will suffer permanent physical damage.
-
Page 15: Using A Web Brower
5. Using a Web Brower This section provides instructions for remotely accessing the camera using a Web browser, such as the Microsoft Internet Explorer. NOTE: Your DVR must be configured with a network connection to provide this access. 5.1 Connecting to the Camera Start your Web browser (for example, the Microsoft Internet Explorer) and then follow these steps to connect to the DVR: Click on the URL entry box near the top of the Web browser window. -
Page 16: Specifications
6. Specifications TSD-52F0013P0A Model HD-TVI Analog 360° Wide Angle View Camera Lens Fixed wide angle lens. Camera Image Sensor 3MP 1/3” progressive COMS sensor. Resolution 1920x1080. Angle of View 360° Frame Rate 25fps/ 30fps Signal System PAL/ NTSC Image Ceiling: 1P/ 2P/ 1O3R/ 1O1R1P/ 2R1P/ 4R. - Page 17 VIDEOR E. Hartig GmbH Exclusive distribution through special- ised trade channels only. VIDEOR E. Hartig GmbH Carl-Zeiss-Straße 8 63322 Rödermark/Germany Tel. +49 (0) 6074 / 888-0 Technical changes reserved Fax +49 (0) 6074 / 888-100 www.videor.com...
