Page 1: Quick Installation Guide
Quick Installation Guide 1/2.8” HD-TVI Dome, PTZ, 12x, Day&Night, 4.8-57.6mm, 1920x1080, WDR, IP66 TPP-62A0012M0A... -
Page 2: Table Of Contents
Content Safety instructions General safety instructions Components........................5 • Before switching on and operating the system, first read this safety advice and the operating instructions. • Keep the operating instructions in a safe place for later use. Installation ........................6 • Installation, commissioning and maintenance of the system may only be carried out by authorised individuals and in accordance with the installation instructions - ensuring that all applicable standards and Installation ...................................6 guidelines are followed. -
Page 3: Components
Components Class A device note This is a Class A device. This device can cause malfunctions in the living area; in such an event, the operator may This system comes with the following components; need to take appropriate measures to compensate for these. WEEE (Waste Electronical &... -
Page 4: Installation
Installation 2. Fix the Mounting Bracket to the ceiling using supplied Anchors (4x) and Mounting Screws (4x) (Figure B). 3. Hook up the Safety Lanyard to the Safety Lanyard Hook of the Mounting Bracket Installation (Figure C). 4. Align the locking tab on the bracket and the locking slot on the base of the dome The dome camera is for use in surface or pendent mounting applications, and the mount- (Figure D). -
Page 5: Basic Configuration Of Camera System
CAUTION: Before installing mounting bracket to surface pre-adjust the four mounting BNC jack BLACK CVBS OUTPUT screws ”A” on the base of the dome camera to best match the mounting bracket locked position. Unscrew the locking screw on the side of the dome’s base and fit the tab of the mounting bracket into the locking slot. -
Page 6: Connections
Pelco-C Reserved AO1,AO2 (5VTTL Alarm Output 1,2) Reserved Reserved Reserved Reserved The dome camera can activate external devices such as buzzers or lights. Connect the device to the AO1,AO2 (Alarm Output 1,2) and G (Ground) connectors. See Program and Operation for configuring alarm output. Connections Connecting the Power Connecting to the RS-485... -
Page 7: Program And Operation
Program and Operation Further information The manual is also available from the eneo web site at www.eneo-security.com. Dome Camera Selection Before you program or operate a dome camera, you must select the dome camera by pressing No. + CAM keys. - Page 9 VIDEOR E. Hartig GmbH Exclusive distribution through specialised trade channels only. VIDEOR E. Hartig GmbH Carl-Zeiss-Straße 8 63322 Rödermark/Germany Tel. +49 (0) 6074 / 888-0 Technical changes reserved Fax +49 (0) 6074 / 888-100 www.videor.com...
